4-inch LF driver · SP series · 25 mm voice coil · 30 W

Monacor SP-4/60PRO 8Ω

Name: Monacor SP-4/60PRO 8 Ohm
Brand: Monacor
SKU: SP-4/60PRO

8 Ω · 3–10000 Hz

No price for delivery to the UK

All 1 offer

Open in 00 Simulator

Fs: 92Hz
Xmax: 2.3mm
SPL: 88dB
Pe: 30W
BL: 5.8T·m
Vd: 16cm³
Qts: 0.60
Vas: 3L

See all 26 specs

Specifications

Published by Monacor

Manufacturer page

Datasheet PDF

Monacor SP-4/60PRO is a 4-inch 8 ohm LF driver rated at 30 W RMS. The validated T/S data includes Fs 92 Hz, Qts 0.60, Vas 3 L, Xmax 2.3 mm, sensitivity 87.5 dB, plus 16 cm³ Vd and 137 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 92Hz
Qts: 0.60
Qes: 0.67
Qms: 5.3
Vas: 3L
Re: 6.8Ω
Le: 0.30mH

Motor and cone

BL: 5.8T·m
Sd: 68cm²
Mms: 6g
Xmax: 2.3mm
Vd †: 16cm³
Voice coil: 25mm

Power and response

Sensitivity †: 87.5dB
Manufacturer sensitivity: 90dB
Power: 30W
Impedance: 8Ω
Range: 3–10000Hz
EBP †: 137 · Leans vented

Size and mounting

Diameter: 113mm
Cutout: 103mm
Depth: 63mm
Weight: 0.9kg

Other published values

Cms: 0.47mm/N
Power Peak: 60

Other dimensions

Mounting Depth: 57.5

Sensitivity shows 87.5 dB, calculated from the T/S values. Monacor publishes 90.0 dB, 2.5 dB apart.

† Calculated by bits from the published values

What this validation status means

Everything else Monacor lists

MF · Primary · 4″

BL: 5.8T·m
Fs: 92Hz
Le: 0.30mH
Re: 6.8Ω
Sd: 68cm²
Cms: 0.47mm/N
Mms: 6g
Qes: 0.67
Qms: 5.3
Qts: 0.60
SPL: 87.5dB
Vas: 3L
Xmax: 2.3mm
Power: 30W
Impedance: 8Ω
Power Peak: 60
Sensitivity: 90dB
Low limit: 3Hz
Calculated sensitivity †: 87.5dB
High limit: 10000Hz
Manufacturer sensitivity: 90dB
Voice coil: 25mm
Weight: 0.9kg
Diameter: 113mm
Depth: 63mm
Mounting Depth: 57.5
Cutout: 103mm

Compare

Same-size drivers, compared with the SP-4/60PRO. Clear differences are green when better and red when worse.

This driverSP-4/60PRO

Best price

–

92 Hz

Qts

0.60

Vas

3 L

5.8 T·m

Xmax

2.3 mm

Sensitivity

87.5 dB

Power

30 W

REDCATT5FR

£15.83

Fs92 Hz –

Qts0.69 +15%

Vas3.8 L +27%

BL6.3 T·m +8%

Xmax2 mm −13%

Sensitivity88.1 dB +0.6

Dayton AudioPA130-8

£17.94

Fs83 Hz −9%

Qts0.51 −15%

Vas4.0 L +32%

BL6.4 T·m +10%

Xmax2 mm −13%

Sensitivity87.8 dB –

Sica3.5 H 1 CS

£18.42

Fs85 Hz −8%

Qts0.53 −12%

Vas1.8 L −40%

BL4.8 T·m −17%

Xmax2.5 mm +9%

Sensitivity84.9 dB −2.6

FaitalPRO4FE32

£21.94

Fs100 Hz +9%

Qts0.61 –

Vas2.3 L −23%

BL4.8 T·m −18%

Xmax2.7 mm +19%

Sensitivity87.2 dB –

Dayton AudioDMA105-8

£22.10

Fs72 Hz −22%

Qts0.63 +5%

Vas4.2 L +42%

BL4.5 T·m −23%

Xmax2.5 mm +9%

Sensitivity84.8 dB −2.7

CIAREPA087

£24.28

Fs74 Hz −20%

Qts0.62 +3%

Vas2.2 L −27%

BL3.5 T·m −41%

Xmax2 mm −13%

Sensitivity83 dB −4.5

Sica4 L 1 SL

£25.87

Fs108 Hz +18%

Qts0.63 +5%

Vas1.2 L −60%

BL5.1 T·m −13%

Xmax2.4 mm +4%

Sensitivity84.9 dB −2.6

LavoceCSF051.21

£29.17

Fs110 Hz +20%

Qts0.64 +7%

Vas4.1 L +36%

BL5.9 T·m –

Xmax3.4 mm +48%

Sensitivity90.7 dB +3.2

CelestionTF0510

£29.30

Fs128 Hz +39%

Qts0.58 −3%

Vas7.4 L +146%

BL6.8 T·m +17%

Xmax2.4 mm +4%

Sensitivity95.1 dB +7.6

Dayton AudioND105-8

£30.48

Fs67 Hz −28%

Qts0.66 +10%

Vas3.0 L –

BL5.4 T·m −7%

Xmax4 mm +74%

Sensitivity82.8 dB −4.7

Dayton AudioND105-4

£30.48

Fs79 Hz −14%

Qts0.61 –

Vas2.0 L −34%

BL4.5 T·m −23%

Xmax4 mm +74%

Sensitivity83.7 dB −3.8

CIAREPA100

£30.98

Fs100 Hz +9%

Qts0.59 –

Vas2.5 L −17%

BL4.4 T·m −25%

Xmax2.5 mm +9%

Sensitivity87.6 dB –

CelestionAN3510

£41.86

Fs113 Hz +23%

Qts0.65 +8%

Vas1.9 L −38%

BL4.6 T·m −22%

Xmax2.3 mm –

Sensitivity87.7 dB –

Dayton AudioRS125T-8

£47.22

Fs76 Hz −17%

Qts0.50 −17%

Vas3.6 L +19%

BL5.0 T·m −14%

Xmax2.8 mm +22%

Sensitivity86.1 dB −1.4

Sica5 N 1.5 PL

£65.31

Fs111 Hz +20%

Qts0.56 −7%

Vas3 L –

BL6.2 T·m +6%

Xmax3 mm +30%

Sensitivity89.5 dB +2

Scanspeak10F/8414G10

£66.31

Fs100 Hz +9%

Qts0.51 −15%

Vas1.6 L −48%

BL4.3 T·m −26%

Xmax2.3 mm –

Sensitivity85.9 dB −1.6

CelestionTFX0412

£69.00

Fs95 Hz +3%

Qts0.59 –

Vas2.2 L −27%

BL5.4 T·m −8%

Xmax4 mm +74%

Sensitivity86.5 dB −1

VisatonB 80

£72.39

Fs110 Hz +20%

Qts0.63 +5%

Vas1.8 L −40%

BL4.2 T·m −29%

Xmax2.2 mm −4%

Sensitivity87.4 dB –

WavecorWF118WA06

£82.89

Fs66 Hz −28%

Qts0.55 −8%

Vas3.5 L +17%

BL5.6 T·m −4%

Xmax3 mm +30%

Sensitivity84.3 dB −3.2

AccutonC90-6-724

£527.46

Fs83 Hz −10%

Qts0.60 –

Vas5.1 L +70%

BL6.0 T·m –

Xmax3 mm +30%

Sensitivity88.4 dB +0.9

ScanspeakD8404/552000

£2,428.16

Fs280 Hz +204%

Qts0.69 +15%

Vas0.27 L −91%

BL6.1 T·m +4%

Xmax2.4 mm +4%

Sensitivity90.6 dB +3.1

LavoceWSF051.02

No current price

Fs106 Hz +15%

Qts0.60 –

Vas3.3 L +9%

BL6.4 T·m +9%

Xmax3.1 mm +35%

Sensitivity89.7 dB +2.2

CIARECM133

No current price

Fs112 Hz +22%

Qts0.54 −10%

Vas2.5 L −17%

BL5.0 T·m −14%

Xmax2 mm −13%

Sensitivity89 dB +1.5

REDCATT35FR-2

No current price

Fs128 Hz +39%

Qts0.63 +5%

Vas1.1 L −62%

BL4.8 T·m −18%

Xmax2.4 mm –

Sensitivity87.5 dB –

Dayton AudioCFC120-8

No current price

Fs60 Hz −35%

Qts0.56 −7%

Vas4.6 L +54%

BL5.1 T·m −12%

Xmax2.5 mm +9%

Sensitivity83.6 dB −3.9

WavecorMR120BD03

No current price

Fs73 Hz −21%

Qts0.56 −7%

Vas3.1 L +3%

BL5.2 T·m −11%

Xmax1.5 mm −35%

Sensitivity85.1 dB −2.4

Dayton AudioDMA90-8

No current price

Fs94 Hz –

Qts0.57 −5%

Vas1.7 L −43%

BL4.7 T·m −20%

Xmax2.5 mm +9%

Sensitivity84.9 dB −2.6

WavecorMR120BD04

No current price

Fs72 Hz −22%

Qts0.55 −8%

Vas3.2 L +7%

BL5.2 T·m −11%

Xmax1.5 mm −35%

Sensitivity85.1 dB −2.4

EminenceALPHA 4-4

No current price

Fs120 Hz +30%

Qts0.63 +5%

Vas1.8 L −41%

BL4.1 T·m −30%

Xmax2.6 mm +13%

Sensitivity88.4 dB +0.9

WavecorWF120BD07

No current price

Fs72 Hz −22%

Qts0.51 −15%

Vas3.3 L +8%

BL5.5 T·m −6%

Xmax4 mm +74%

Sensitivity85.3 dB −2.2
