HiVi B4N 8Ω
8 Ω
No price for delivery to the UK
- Fs
- 56Hz
- Xmax
- 3.2mm
- SPL
- 83dB
- Pe
- 25W
- BL
- 5.1T·m
- Vd
- 17cm³
- Qts
- 0.52
- Vas
- 5L
HiVi B4N is a 4-inch 8 ohm LF driver rated at 25 W RMS. The validated T/S data includes Fs 56 Hz, Qts 0.52, Vas 4.5 L, Xmax 3.2 mm, sensitivity 83 dB, plus 17 cm³ Vd and 89 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 56Hz
- Qts
- 0.52
- Qes
- 0.63
- Qms
- 3.9
- Vas
- 4.5L
- Re
- 6.5Ω
Motor and cone
- BL
- 5.1T·m
- Sd Derived
- 54cm²
- Mms
- 7g
- Xmax
- 3.2mm
- Vd †
- 17cm³
- Voice coil
- 25mm
Power and response
- Sensitivity †
- 83dB
- Manufacturer sensitivity
- 85dB
- Power
- 25W
- Impedance
- 8Ω
- EBP †
- 89 · Sealed or vented
Size and mounting
- Weight
- 0.8kg
Other published values
- Cms
- 1.11mm/N
- Power Peak
- 50
Sensitivity shows 83.0 dB, calculated from the T/S values. HiVi publishes 85.0 dB, 2.0 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else HiVi lists
LF · Primary · 4″
- BL
- 5.1T·m
- Fs
- 56Hz
- Re
- 6.5Ω
- Sd
- 54cm²
- Cms
- 1.11mm/N
- Mms
- 7g
- Qes
- 0.63
- Qms
- 3.9
- Qts
- 0.52
- SPL
- 83dB
- Vas
- 4.5L
- Xmax
- 3.2mm
- Power
- 25W
- Impedance
- 8Ω
- Power Peak
- 50
- Sensitivity
- 85dB
- Calculated sensitivity †
- 83dB
- Manufacturer sensitivity
- 85dB
- Voice coil
- 25mm
- Weight
- 0.8kg
