Overview
LF DriverFSL series
Peerless
Peerless FSL-0512R01-08
Peerless FSL-0512R01-08 is a 5.25" 8 ohm LF driver rated at 90W RMS. The validated T/S data includes Fs 120Hz, Qts 0.58, Vas 3.5L, Xmax 4.3mm, sensitivity 91dB, plus 43cm³ Vd and 158 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
5.25"
Impedance
8Ω
RMS Power
90W
Sensitivity
91.0dB
EBP
158
Vented alignment
Vd
43cm³
T/S Parameters
Valid
Fs120Hz
Qts0.58
Qes0.76
Qms2.4
Vas3.5L
Re5.9Ω
Le0.28mH
BL6.4Tm
Sd100cm²
Mms7g
Xmax4.3mm
SPL91dB
Power90W
Impedance8Ω
Pricing & availability
Price definitionsNo current price found
Pricing may appear after the next vendor refresh.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.0kg
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Peerless
FSL-0512R01-08
5.25"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
73%
Similarity
£41.18
Dayton Audio
LW150-4
6"
Xmax4mm-8%
Qts0.64+10%
BL6.5Tm+1%
Vas3.5L0%
Qes0.72-5%
73%
Similarity
Celestion
TF0512HE
5"
Xmax4.8mm+10%
Qts0.54-8%
BL6.7Tm+4%
Vas3.5L-1%
Qes0.57-25%
70%
Similarity
£14.72
Lavoce
WSF051.02
5"
Xmax3.1mm-28%
Qts0.6+3%
BL6.4Tm-1%
Vas3.3L-6%
Qes0.66-13%
67%
Similarity
Lavoce
CSF051.21
5"
Xmax3.4mm-21%
Qts0.64+10%
BL5.9Tm-8%
Vas4.1L+17%
Qes0.74-3%
65%
Similarity
£64.09
Eminence
BETA-6A
6"
Xmax4.5mm+4%
Qts0.56-3%
BL8.1Tm+26%
Vas3.5L+1%
Qes0.66-13%
64%
Similarity
FaitalPRO
5HX220
5"
Xmax4.6mm+6%
Qts0.56-3%
BL7.7Tm+20%
Vas2.5L-28%
Qes0.6-21%
58%
Similarity
£29.50
FaitalPRO
6FE200
6"
Xmax4.7mm+8%
Qts0.67+16%
BL8.2Tm+27%
Vas3.6L+3%
Qes0.75-1%
55%
Similarity
Peerless
GBS-135F25AL02-04
5.25"
Xmax5.4mm+24%
Qts0.59+2%
BL4.9Tm-23%
Vas5.3L+52%
Qes0.68-10%
Image unavailable
51%
Similarity
Wavecor
SW118WA02
4.5"
Xmax4mm-8%
Qts0.47-19%
BL5.9Tm-8%
Vas3.3L-5%
Qes0.5-34%
49%
Similarity
£33.69
Dayton Audio
RS125P-8
5"
Xmax4mm-8%
Qts0.44-24%
BL5.1Tm-21%
Vas4L+14%
Qes0.53-30%
46%
Similarity
Peerless
GBS-115N25AL01-04
4.5"
Xmax4.8mm+12%
Qts0.63+9%
BL4.5Tm-30%
Vas1.8L-49%
Qes0.77+2%
40%
Similarity
£24.49
FaitalPRO
5FE120
5"
Xmax5.3mm+21%
Qts0.48-17%
BL6.9Tm+7%
Vas5.4L+55%
Qes0.51-33%
