Overview
LF Driver
Sica
Sica 12 D 1.5 CS
Sica 12 D 1.5 CS is a 12" 8 ohm LF driver rated at 130W RMS. The validated T/S data includes Fs 62Hz, Qts 0.75, Vas 63.5L, Xmax 2.7mm, sensitivity 94.9dB, plus 133cm³ Vd and 79 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
130W
Sensitivity
94.9dB
96.9dBmanufacturer; using T/S-derived value (2.0dB delta).
EBP
79
Either alignment
Vd
133cm³
T/S Parameters
Valid
Fs62Hz
Qts0.75
Qes0.78
Qms18.3
Vas63.5L
Re5.1Ω
Le0.35mH
BL9.5Tm
Sd491cm²
Mms36g
Xmax2.7mm
SPL95dB
Power130W
Impedance8Ω
Flux Density1.21T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.7kg
Diameter318.0mm
Overall Depth134.7mm
Cutout Diameter287.0mm
Bolt Circle Diameter300.0mm
