12-inch LF driver · TEXAS HEAT series · 150 W
Eminence TEXAS HEAT-4 4Ω
4 Ω · 70–4000 Hz
No price for delivery to the UK
- Fs
- 89Hz
- Xmax
- 0.8mm
- SPL
- 98dB
- Pe
- 150W
- BL
- 9.5T·m
- Vd
- 42cm³
- Qts
- 0.68
- Vas
- 39L
Eminence TEXAS HEAT-4 is a 12-inch 4 ohm LF driver rated at 150 W RMS. The validated T/S data includes Fs 89 Hz, Qts 0.68, Vas 39 L, Xmax 0.8 mm, sensitivity 98 dB, plus 42 cm³ Vd and 127 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £109.49.
The published T/S values agree with each other
Thiele/Small
- Fs
- 89Hz
- Qts
- 0.68
- Qes
- 0.70
- Qms
- 21.1
- Vas
- 39L
- Re
- 3.8Ω
- Le
- 0.50mH
Motor and cone
- BL
- 9.5T·m
- Sd
- 520cm²
- Mms
- 30g
- Xmax
- 0.8mm
- Vd †
- 42cm³
Power and response
- Sensitivity †
- 98dB
- Manufacturer sensitivity
- 99dB
- Power
- 150W
- Impedance
- 4Ω
- Range
- 70–4000Hz
- EBP †
- 127 · Leans vented
Size and mounting
- Diameter
- 305.6mm
- Cutout
- 281.2mm
- Depth
- 129.5mm
- Weight
- 3.8kg
Other published values
- Cms
- 0.11mm/N
Sensitivity shows 98.0 dB, calculated from the T/S values. Eminence publishes 99.0 dB, 1.0 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 12″
- BL
- 9.5T·m
- Fs
- 89Hz
- Le
- 0.50mH
- Re
- 3.8Ω
- Sd
- 520cm²
- Cms
- 0.11mm/N
- Mms
- 30g
- Qes
- 0.70
- Qms
- 21.1
- Qts
- 0.68
- SPL
- 98dB
- Vas
- 39L
- Xmax
- 0.8mm
- Power
- 150W
- Impedance
- 4Ω
- Sensitivity
- 99dB
- Low limit
- 70Hz
- Calculated sensitivity †
- 98dB
- High limit
- 4000Hz
- Manufacturer sensitivity
- 99dB
- Weight
- 3.8kg
- Diameter
- 305.6mm
- Depth
- 129.5mm
- Cutout
- 281.2mm
