Overview
LF DriverLEGEND GB series
Eminence
Eminence LEGEND GB128
Eminence LEGEND GB128 is a 12" 8 ohm LF driver rated at 50W RMS. The validated T/S data includes Fs 86Hz, Qts 0.65, Vas 43.9L, Xmax 0.8mm, sensitivity 98.2dB, plus 41cm³ Vd and 128 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £105.00.
Size
12"
Impedance
8Ω
RMS Power
50W
Sensitivity
98.2dB
101.3dBmanufacturer; using T/S-derived value (3.1dB delta).
EBP
128
Vented alignment
Vd
41cm³
T/S Parameters
Valid
Fs86Hz
Qts0.65
Qes0.67
Qms19.5
Vas43.9L
Re6.4Ω
Le0.64mH
BL12.0Tm
Sd507cm²
Mms28g
Xmax0.8mm
SPL98dB
Power50W
Impedance8Ω
F Low80Hz
F High5100Hz
Pricing & availability
Price definitionsPrice movement
Other offers
2 vendorsleanaudio
Updated 25 Sept 2026· 8Ω
Source: inc VAT · 20%
£105.00
inc VAT
1 in stock
thomann
Updated 25 Sept 2026· 8Ω
Source: inc VAT · 20%
£121.00
inc VAT
In stock
Best current price
Updated 25 Sept 2026
leanbusiness
£105.00
Avg £110.33£5.33 below avg (-4.8%)
inc VAT
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.7kg
Diameter305.6mm
Overall Depth129.5mm
Cutout Diameter281.2mm
