12-inch LF driver · TEXAS HEAT series · 150 W
Eminence TEXAS HEAT 8Ω
8 Ω · 70–4700 Hz
No price for delivery to the UK
- Fs
- 79Hz
- Xmax
- 0.8mm
- SPL
- 98dB
- Pe
- 150W
- BL
- 12.8T·m
- Vd
- 42cm³
- Qts
- 0.65
- Vas
- 51L
Eminence TEXAS HEAT is a 12-inch 8 ohm LF driver rated at 150 W RMS. The validated T/S data includes Fs 79 Hz, Qts 0.65, Vas 50.9 L, Xmax 0.8 mm, sensitivity 97.7 dB, plus 42 cm³ Vd and 116 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £109.49.
The published T/S values agree with each other
Thiele/Small
- Fs
- 79Hz
- Qts
- 0.65
- Qes
- 0.68
- Qms
- 13.9
- Vas
- 50.9L
- Re
- 7.3Ω
- Le
- 0.54mH
Motor and cone
- BL
- 12.8T·m
- Sd
- 520cm²
- Mms
- 31g
- Xmax
- 0.8mm
- Vd †
- 42cm³
Power and response
- Sensitivity †
- 97.7dB
- Manufacturer sensitivity
- 99.4dB
- Power
- 150W
- Impedance
- 8Ω
- Range
- 70–4700Hz
- EBP †
- 116 · Leans vented
Size and mounting
- Cutout
- 281.2mm
Other published values
- Cms
- 0.13mm/N
Sensitivity shows 97.7 dB, calculated from the T/S values. Eminence publishes 99.4 dB, 1.7 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 12″
- BL
- 12.8T·m
- Fs
- 79Hz
- Le
- 0.54mH
- Re
- 7.3Ω
- Sd
- 520cm²
- Cms
- 0.13mm/N
- Mms
- 31g
- Qes
- 0.68
- Qms
- 13.9
- Qts
- 0.65
- SPL
- 97.7dB
- Vas
- 50.9L
- Xmax
- 0.8mm
- Power
- 150W
- Impedance
- 8Ω
- Sensitivity
- 99.4dB
- Low limit
- 70Hz
- Calculated sensitivity †
- 97.7dB
- High limit
- 4700Hz
- Manufacturer sensitivity
- 99.4dB
- Cutout
- 281.2mm
02
Compare
Same-size drivers, compared with the TEXAS HEAT. Clear differences are green when better and red when worse.
This driverTEXAS HEAT
Best price
£109.49
Fs
79 Hz
Qts
0.65
Vas
50.9 L
BL
12.8 T·m
Xmax
0.8 mm
Sensitivity
97.7 dB
Power
150 W
PeerlessFSL-1220R02-08
£59.63 · 46% less, betterFs62 Hz −22%, better
Qts0.55 −15%, better
Vas61.1 L +20%, worse
BL13.3 T·m +4%
Xmax5.1 mm +534%, better
Sensitivity96 dB −1.7
£75.00 · 31% less, better
Fs50 Hz −37%, better
Qts0.64 –
Vas78.1 L +53%, worse
BL13 T·m –
Xmax3.5 mm +338%, better
Sensitivity93.3 dB −4.4, worse
PeerlessSLS-P830669
£75.21 · 31% less, betterFs34 Hz −57%, better
Qts0.64 –
Vas107 L +110%, worse
BL11.8 T·m −8%
Xmax10.9 mm +1262%, better
Sensitivity90 dB −7.7, worse
CelestionTRUVOX 1225
£88.68 · 19% less, betterFs60 Hz −24%, better
Qts0.62 −4%
Vas54.1 L +6%
BL13.5 T·m +6%
Xmax4.8 mm +494%, better
Sensitivity94.4 dB −3.3, worse
EminenceMAN O WAR
£99.00 · 10% less, betterFs91 Hz +15%, worse
Qts0.68 +5%
Vas38 L −25%, better
BL12.3 T·m −4%
Xmax0.8 mm –
Sensitivity98 dB –
EminenceLEGEND GB128
£105.00 · 4% lessFs86 Hz +9%
Qts0.65 –
Vas43.9 L −14%, better
BL12 T·m −6%
Xmax0.8 mm –
Sensitivity98.2 dB +0.5
EminenceTEXAS HEAT-4
£109.49 · Same priceFs89 Hz +13%, worse
Qts0.68 +5%
Vas39 L −23%, better
BL9.5 T·m −26%, worse
Xmax0.8 mm –
Sensitivity98 dB –
EminenceTEXAS HEAT-16
£109.49 · Same priceFs91 Hz +15%, worse
Qts0.81 +25%, worse
Vas44.5 L −13%, better
BL16 T·m +25%, better
Xmax0.8 mm –
Sensitivity97.9 dB –
EminenceSWAMP THANG-16
£125.37 · 15% more, worseFs113 Hz +43%, worse
Qts0.62 −5%
Vas26.4 L −48%, better
BL21.8 T·m +70%, better
Xmax0.8 mm –
Sensitivity99.6 dB +1.9
EminenceGA-SC59
£230.67 · 111% more, worseFs89 Hz +13%, worse
Qts0.61 −6%
Vas41.2 L −19%, better
BL13.6 T·m +6%
Xmax1.6 mm +101%, better
Sensitivity98.7 dB +1
Dayton AudioUMII12-22
£250.69 · 129% more, worseFs31 Hz −61%, better
Qts0.56 −14%, better
Vas53 L +4%
BL14.8 T·m +16%, better
Xmax22 mm +2650%, better
Sensitivity85.5 dB −12.2, worse
EminenceJS-1250
No current priceFs92 Hz +16%, worse
Qts0.61 −6%
Vas41.2 L −19%, better
BL12.9 T·m –
Xmax0.8 mm –
Sensitivity99.1 dB +1.4
EminenceGUIT-FIDDLE
No current priceFs82 Hz +4%
Qts0.56 −14%, better
Vas57.8 L +14%, worse
BL13.1 T·m –
Xmax0.8 mm –
Sensitivity99.4 dB +1.7
EminenceGA-SC-X
No current priceFs91 Hz +15%, worse
Qts0.66 –
Vas45.0 L −12%, better
BL12.2 T·m −5%
Xmax1.3 mm +59%, better
Sensitivity98.8 dB +1.1
REDCATT121FIND
No current priceFs63 Hz −20%, better
Qts0.60 −8%
Vas49.8 L –
BL12.9 T·m –
Xmax3.8 mm +369%, better
Sensitivity94.9 dB −2.8, worse
JensenC12-75NH-8
No current priceFs83 Hz +5%
Qts0.64 –
Vas42.4 L −17%, better
BL11.8 T·m −8%
Xmax1 mm +25%, better
Sensitivity97.1 dB −0.6
EminenceSWAMP THANG
No current priceFs97 Hz +23%, worse
Qts0.53 −18%, better
Vas41.3 L −19%, better
BL14.2 T·m +11%, better
Xmax0.8 mm –
Sensitivity100.4 dB +2.7, better
JensenJN12-80TRS-8
No current priceFs72 Hz −9%
Qts0.55 −15%, better
Vas56.5 L +11%, worse
BL12.2 T·m −5%
Xmax1 mm +25%, better
Sensitivity96.7 dB −1
P.AudioE12-200S-V2
No current priceFs65 Hz −18%, better
Qts0.69 +6%
Vas42.2 L −17%, better
BL12.3 T·m −4%
Xmax4.1 mm +412%, better
Sensitivity93.9 dB −3.8, worse
CelestionTF1230
No current priceFs59 Hz −25%, better
Qts0.52 −21%, better
Vas51.1 L –
BL13.0 T·m –
Xmax5 mm +525%, better
Sensitivity94.1 dB −3.6, worse
JensenJN12-100TRS-8
No current priceFs72 Hz −9%
Qts0.52 −20%, better
Vas55.9 L +10%
BL12.9 T·m –
Xmax1 mm +25%, better
Sensitivity96.5 dB −1.2
LavoceWSF121.70G
No current priceFs82 Hz +4%
Qts0.59 −9%
Vas41 L −19%, better
BL13.6 T·m +6%
Xmax2.7 mm +238%, better
Sensitivity97.6 dB –
No current price
Fs50 Hz −37%, better
Qts0.64 –
Vas78.1 L +53%, worse
BL13 T·m –
Xmax5.3 mm +556%, better
Sensitivity93.3 dB −4.4, worse
EminenceGA-SC64
No current priceFs88 Hz +11%, worse
Qts0.58 −11%, better
Vas45.0 L −12%, better
BL13.8 T·m +8%
Xmax1.2 mm +54%, better
Sensitivity99.1 dB +1.4
P.AudioEX12-300S
No current priceFs66 Hz −16%, better
Qts0.54 −17%, better
Vas45.9 L −10%
BL13.7 T·m +7%
Xmax3.1 mm +287%, better
Sensitivity95.2 dB −2.5, worse
Acoustic EleganceIB12HT-8
No current priceFs17 Hz −79%, better
Qts0.64 –
Vas179.5 L +253%, worse
BL12.5 T·m –
Xmax18.5 mm +2212%, better
Sensitivity82.6 dB −15.1, worse
PeerlessFSL-1230R04-04
No current priceFs56 Hz −29%, better
Qts0.54 −17%, better
Vas47.4 L −7%
BL11.9 T·m −7%
Xmax7.2 mm +796%, better
Sensitivity93.7 dB −4, worse
JensenJN12-100TR-4
No current priceFs77 Hz −3%
Qts0.58 −11%, better
Vas47.2 L −7%
BL9.0 T·m −30%, worse
Xmax1 mm +25%, better
Sensitivity96.6 dB −1.1
JensenJC12-70EL-8
No current priceFs95 Hz +20%, worse
Qts0.67 +3%
Vas32 L −37%, better
BL12.7 T·m –
Xmax1 mm +25%, better
Sensitivity96.7 dB −1
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
