Eminence THE TONKER 8Ω
8 Ω · 70–5000 Hz
£102.56
SteadyLean Audio · 1 in stock · All 3 offers
- Fs
- 89Hz
- Xmax
- 0.8mm
- SPL
- 99dB
- Pe
- 150W
- BL
- 17.4T·m
- Vd
- 42cm³
- Qts
- 0.47
- Vas
- 34L
Eminence THE TONKER is a 12-inch 8 ohm LF driver rated at 150 W RMS. The validated T/S data includes Fs 89 Hz, Qts 0.47, Vas 34.1 L, Xmax 0.8 mm, sensitivity 98.9 dB, plus 42 cm³ Vd and 182 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £102.56.
The published T/S values agree with each other
Thiele/Small
- Fs
- 89Hz
- Qts
- 0.47
- Qes
- 0.49
- Qms
- 10.0
- Vas
- 34.1L
- Re
- 7.4Ω
- Le
- 0.47mH
Motor and cone
- BL
- 17.4T·m
- Sd
- 520cm²
- Mms
- 36g
- Xmax
- 0.8mm
- Vd †
- 42cm³
Power and response
- Sensitivity †
- 98.9dB
- Manufacturer sensitivity
- 101.5dB
- Power
- 150W
- Impedance
- 8Ω
- Range
- 70–5000Hz
- EBP †
- 182 · Leans vented
Size and mounting
- Diameter
- 305.6mm
- Cutout
- 281.2mm
- Depth
- 132.1mm
- Weight
- 5.0kg
Other published values
- Cms
- 0.09mm/N
Sensitivity shows 98.9 dB, calculated from the T/S values. Eminence publishes 101.5 dB, 2.6 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 12″
- BL
- 17.4T·m
- Fs
- 89Hz
- Le
- 0.47mH
- Re
- 7.4Ω
- Sd
- 520cm²
- Cms
- 0.09mm/N
- Mms
- 36g
- Qes
- 0.49
- Qms
- 10.0
- Qts
- 0.47
- SPL
- 98.9dB
- Vas
- 34.1L
- Xmax
- 0.8mm
- Power
- 150W
- Impedance
- 8Ω
- Sensitivity
- 101.5dB
- Low limit
- 70Hz
- Calculated sensitivity †
- 98.9dB
- High limit
- 5000Hz
- Manufacturer sensitivity
- 101.5dB
- Weight
- 5.0kg
- Diameter
- 305.6mm
- Depth
- 132.1mm
- Cutout
- 281.2mm
