Overview
LF DriverTHE TONKER series
Eminence
Eminence THE TONKER
Eminence THE TONKER is a 12" 8 ohm LF driver rated at 150W RMS. The validated T/S data includes Fs 89Hz, Qts 0.47, Vas 34.1L, Xmax 0.8mm, sensitivity 98.9dB, plus 42cm³ Vd and 182 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £102.56.
Size
12"
Impedance
8Ω
RMS Power
150W
Sensitivity
98.9dB
101.5dBmanufacturer; using T/S-derived value (2.6dB delta).
EBP
182
Vented alignment
Vd
42cm³
T/S Parameters
Valid
Fs89Hz
Qts0.47
Qes0.49
Qms10.0
Vas34.1L
Re7.4Ω
Le0.47mH
BL17.4Tm
Sd520cm²
Mms36g
Xmax0.8mm
SPL99dB
Power150W
Impedance8Ω
F Low70Hz
F High5000Hz
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorleanbusiness
Updated 25 Sept 2026· 8Ω
Source: inc VAT · 20%
£114.00
inc VAT
Best current price
Updated 25 Sept 2026
leanaudio
£102.56
Avg £108.28
inc VAT·1 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight5.0kg
Diameter305.6mm
Overall Depth132.1mm
Cutout Diameter281.2mm
