Overview
LF DriverDELTA series
Eminence
Eminence DELTA 12B
Eminence DELTA 12B is a 12" 16 ohm LF driver rated at 400W RMS. The validated T/S data includes Fs 58Hz, Qts 0.48, Vas 87L, Xmax 2.7mm, sensitivity 97.2dB, plus 140cm³ Vd and 112 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £99.00.
Size
12"
Impedance
16Ω
RMS Power
400W
Sensitivity
97.2dB
98.3dBmanufacturer; using T/S-derived value (1.1dB delta).
EBP
112
Vented alignment
Vd
140cm³
T/S Parameters
Valid
Fs58Hz
Qts0.48
Qes0.52
Qms7.0
Vas87.0L
Re11.4Ω
Le0.77mH
BL16.0Tm
Sd520cm²
Mms32g
Xmax2.7mm
SPL97dB
Power400W
Impedance16Ω
F Low65Hz
F High5000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£99.00
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight5.2kg
Diameter305.6mm
Overall Depth135.9mm
Cutout Diameter281.2mm
Bolt Circle Diameter294.4mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
DELTA 12B
12"
Best current price
£99.00
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
9 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
67%
Similarity
20% cheaper£79.00
Celestion
K12H-100TC
12"
Lower price
Xmax3mm+11%
Qts0.4-17%
BL13.6Tm-15%
Vas72L-17%
Qes0.47-9%
57%
Similarity
4% cheaper£95.30
Eminence
BETA 12CX
12"
Lower price
Xmax3.5mm+30%
Qts0.480%
BL10.8Tm-33%
Vas120.9L+39%
Qes0.520%
73%
Similarity
1% more£100.00
Eminence
DELTA-12A
12"
Higher price
Xmax2.4mm-11%
Qts0.43-10%
BL13.5Tm-16%
Vas81.3L-7%
Qes0.46-12%
60%
Similarity
8% more£107.29
B&C
320K/C-A
12"
Higher price
Xmax2mm-26%
Qts0.5+4%
BL12.2Tm-24%
Vas53L-39%
Qes0.520%
49%
Similarity
112% more£209.86
B&C
320K/C-A
12"
Higher price
Xmax2mm-26%
Qts0.59+23%
BL16.8Tm+5%
Vas52L-40%
Qes0.61+17%
70%
Similarity
PRV Audio
12MR1000
12"
Xmax3mm+11%
Qts0.39-19%
BL15.9Tm-1%
Vas92.3L+6%
Qes0.4-23%
67%
Similarity
Monacor
K12H-100TC/8
12"
Xmax3mm+11%
Qts0.4-17%
BL13.6Tm-15%
Vas72L-17%
Qes0.47-9%
58%
Similarity
Celestion
TF1218
12"
Xmax2mm-26%
Qts0.52+8%
BL11.2Tm-30%
Vas83L-5%
Qes0.61+17%
55%
Similarity
Lavoce
WSF121.70G
12"
Xmax2.7mm0%
Qts0.59+23%
BL13.6Tm-15%
Vas41L-53%
Qes0.62+19%
