Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespMedia
Overview
LF DriverSB42 series
SB Acoustics
SB Acoustics SB42FHCL75-6
SB Acoustics SB42FHCL75-6 is a 15" 6 ohm LF driver rated at 300W RMS. The validated T/S data includes Fs 18Hz, Qts 0.31, Vas 462L, Xmax 23mm, sensitivity 91.6dB, plus 1955cm³ Vd and 57 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £342.09.
Size
15"
Impedance
6Ω
RMS Power
300W
Sensitivity
91.6dB
93.0dBmanufacturer; using T/S-derived value (1.4dB delta).
EBP
57
Either alignment
Vd
1955cm³
T/S Parameters
Valid
Fs18Hz
Qts0.31
Qes0.32
Qms7.4
Vas462.0L
Re4.6Ω
Le2.10mH
BL16.7Tm
Sd850cm²
Mms166g
Xmax23.0mm
SPL92dB
Power300W
Impedance6Ω
Voice Coil76mm
Flux Density1.10T
Pricing & availability
Price definitionsPrice movement
Best current price
£342.09
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight10.2kg
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
SB Acoustics
SB42FHCL75-6
15"
Best current price
£342.09
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
Loading matches
