REDCATT 8FIND 8Ω
8 Ω
£58.97
Lautsprecherteile · 20 in stock · All 1 offer
- Fs
- 70Hz
- Xmax
- 2.2mm
- SPL
- 96dB
- Pe
- 200W
- BL
- 14.3T·m
- Vd
- 50cm³
- Qts
- 0.25
- Vas
- 18L
REDCATT 8FIND is an 8-inch 8 ohm LF driver rated at 200 W RMS. The validated T/S data includes Fs 70 Hz, Qts 0.25, Vas 18.2 L, Xmax 2.2 mm, sensitivity 96 dB, plus 50 cm³ Vd and 280 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £58.97.
The published T/S values agree with each other
Thiele/Small
- Fs
- 70Hz
- Qts
- 0.25
- Qes
- 0.25
- Qms
- 6.4
- Vas
- 18.2L
- Re
- 5.7Ω
- Le
- 0.48mH
Motor and cone
- BL
- 14.3T·m
- Sd
- 227cm²
- Mms
- 21g
- Xmax
- 2.2mm
- Vd †
- 50cm³
- Voice coil
- 51mm
Power and response
- Sensitivity †
- 96dB
- Manufacturer sensitivity
- 97.3dB
- Power
- 200W
- Impedance
- 8Ω
- EBP †
- 280 · Leans vented
Size and mounting
- Diameter
- 209.5mm
- Cutout
- 185mm
- Bolt circle
- 197.5mm
- Weight
- 3.7kg
Other published values
- Xmech
- 10.2
- Power Peak
- 800
Other dimensions
- Mounting Depth
- 91.5
Sensitivity shows 96.0 dB, calculated from the T/S values. REDCATT publishes 97.3 dB, 1.3 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 8″
- BL
- 14.3T·m
- Fs
- 70Hz
- Le
- 0.48mH
- Re
- 5.7Ω
- Sd
- 227cm²
- Mms
- 21g
- Qes
- 0.25
- Qms
- 6.4
- Qts
- 0.25
- SPL
- 96dB
- Vas
- 18.2L
- Xmax
- 2.2mm
- Xmech
- 10.2
- Power
- 200W
- Impedance
- 8Ω
- Power Peak
- 800
- Sensitivity
- 97.3dB
- Calculated sensitivity †
- 96dB
- Manufacturer sensitivity
- 97.3dB
- Voice coil
- 51mm
- Weight
- 3.7kg
- Diameter
- 209.5mm
- Mounting Depth
- 91.5
- Cutout
- 185mm
- Bolt circle
- 197.5mm
02
Compare
Same-size drivers, compared with the 8FIND. Clear differences are green when better and red when worse.
This driver8FIND
Best price
£58.97
Fs
70 Hz
Qts
0.25
Vas
18.2 L
BL
14.3 T·m
Xmax
2.2 mm
Sensitivity
96 dB
Power
200 W
Beyma8WR300
£91.92 · 56% more, worseFs65 Hz −7%
Qts0.27 +8%
Vas15 L −18%, better
BL15.5 T·m +8%
Xmax6 mm +173%, better
Sensitivity93.6 dB −2.4, worse
Eighteen Sound8M400F
£114.19 · 94% more, worseFs89 Hz +27%, worse
Qts0.26 +4%
Vas13.7 L −25%, better
BL13.1 T·m −8%
Xmax3 mm +36%, better
Sensitivity97.4 dB +1.4
B&C8NDL64
£123.07 · 109% more, worseFs80 Hz +14%, worse
Qts0.25 –
Vas9.6 L −47%, better
BL17.5 T·m +22%, better
Xmax4.5 mm +105%, better
Sensitivity95 dB −1
Sica8 FE 2.5 CP
£132.42 · 125% more, worseFs73 Hz +4%
Qts0.28 +12%, worse
Vas15.6 L −14%, better
BL13.0 T·m −9%
Xmax4 mm +82%, better
Sensitivity95.1 dB −0.9
B&C8MDN51
£136.46 · 131% more, worseFs70 Hz –
Qts0.20 −20%, better
Vas16 L −12%, better
BL15.3 T·m +7%
Xmax6 mm +173%, better
Sensitivity96.2 dB –
Eighteen Sound8NW650
£138.53 · 135% more, worseFs63 Hz −10%, better
Qts0.25 –
Vas17.8 L –
BL15.2 T·m +6%
Xmax5.5 mm +150%, better
Sensitivity94.2 dB −1.8
CelestionFTX0820
£139.00 · 136% more, worseFs79 Hz +13%, worse
Qts0.28 +12%, worse
Vas13.1 L −28%, better
BL14.6 T·m –
Xmax4 mm +82%, better
Sensitivity95.2 dB −0.8
WavecorWF182BD13
£158.81 · 169% more, worseFs38 Hz −46%, better
Qts0.26 +4%
Vas20.8 L +14%, worse
BL6.9 T·m −52%, worse
Xmax5.5 mm +150%, better
Sensitivity88.3 dB −7.7, worse
Sica8 K 3 PL
£161.52 · 174% more, worseFs68 Hz –
Qts0.25 –
Vas12.2 L −33%, better
BL16.1 T·m +13%, better
Xmax5 mm +127%, better
Sensitivity93.6 dB −2.4, worse
MonacorFTX0820/8
£164.51 · 179% more, worseFs79 Hz +13%, worse
Qts0.28 +12%, worse
Vas13.1 L −28%, better
BL14.6 T·m –
Xmax4 mm +82%, better
Sensitivity95.2 dB −0.8
Beyma8MC300ND
£177.28 · 201% more, worseFs62 Hz −11%, better
Qts0.22 −12%, better
Vas18 L –
BL16 T·m +12%, better
Xmax6 mm +173%, better
Sensitivity94.6 dB −1.4
WavecorWF211PA02
£186.66 · 217% more, worseFs59 Hz −16%, better
Qts0.25 –
Vas18.2 L –
BL13.4 T·m −6%
Xmax2 mm −9%
Sensitivity93.6 dB −2.4, worse
WavecorWF211PA01
£186.66 · 217% more, worseFs68 Hz –
Qts0.29 +16%, worse
Vas13.6 L −25%, better
BL10.7 T·m −25%, worse
Xmax2 mm −9%
Sensitivity93.6 dB −2.4, worse
B&C8CXN51
£225.53 · 282% more, worseFs68 Hz –
Qts0.27 +8%
Vas17 L −7%
BL12.6 T·m −12%, worse
Xmax6 mm +173%, better
Sensitivity94.7 dB −1.3
AccutonC173-6-096
£854.59 · 1349% more, worseFs50 Hz −29%, better
Qts0.22 −12%, better
Vas17.0 L −7%
BL11.4 T·m −20%, worse
Xmax5 mm +127%, better
Sensitivity91.5 dB −4.5, worse
Oberton8NB201
No current priceFs71 Hz –
Qts0.24 –
Vas12.5 L −31%, better
BL14.4 T·m –
Xmax5.3 mm +139%, better
Sensitivity94.4 dB −1.6
RCFMB8N251
No current priceFs68 Hz –
Qts0.25 –
Vas13 L −29%, better
BL15.2 T·m +6%
Xmax5 mm +127%, better
Sensitivity94 dB −2, worse
Oberton8NMB250V4
No current priceFs82 Hz +17%, worse
Qts0.26 +3%
Vas10.9 L −40%, better
BL14.3 T·m –
Xmax4.5 mm +105%, better
Sensitivity95.5 dB −0.5
B&C8CLA64
No current priceFs71 Hz –
Qts0.24 −4%
Vas12.5 L −31%, better
BL16.4 T·m +15%, better
Xmax5.3 mm +141%, better
Sensitivity94.6 dB −1.4
Acoustic EleganceTD8M-8
No current priceFs76 Hz +8%
Qts0.26 +4%
Vas11.3 L −38%, better
BL15.5 T·m +8%
Xmax3 mm +36%, better
Sensitivity94.6 dB −1.4
LavoceCAN082.00K
No current priceFs72 Hz –
Qts0.27 +8%
Vas15.1 L −17%, better
BL13.2 T·m −8%
Xmax6.7 mm +205%, better
Sensitivity94.8 dB −1.2
Tang BandW8-740P
No current priceFs30 Hz −57%, better
Qts0.28 +12%, worse
Vas20.0 L +10%, worse
BL13.7 T·m −4%
Xmax12.1 mm +450%, better
Sensitivity84.4 dB −11.6, worse
Oberton8M250
No current priceFs74 Hz +6%
Qts0.20 −20%, better
Vas15.6 L −14%, better
BL13.7 T·m −4%
Xmax2.8 mm +25%, better
Sensitivity97 dB +1
WavecorWF182BD14
No current priceFs36 Hz −49%, better
Qts0.25 –
Vas23 L +26%, worse
BL6.9 T·m −52%, worse
Xmax5.5 mm +150%, better
Sensitivity88.2 dB −7.8, worse
No photo
PHL Audio2510
No current priceFs72 Hz –
Qts0.24 −4%
Vas13.3 L −27%, better
BL23 T·m +61%, better
Xmax4 mm +82%, better
Sensitivity95 dB −1
Oberton8M150
No current priceFs68 Hz –
Qts0.22 −13%, better
Vas21.6 L +19%, worse
BL11.6 T·m −19%, worse
Xmax3.3 mm +48%, better
Sensitivity96.9 dB +0.9
CelestionTN0820
No current priceFs62 Hz −12%, better
Qts0.28 +13%, worse
Vas21.9 L +20%, worse
BL11.8 T·m −18%, worse
Xmax2 mm −9%
Sensitivity93.8 dB −2.2, worse
No photo
PHL Audio2720
No current priceFs50 Hz −29%, better
Qts0.26 +4%
Vas29.2 L +60%, worse
BL12.6 T·m −12%, worse
Xmax9 mm +309%, better
Sensitivity93.3 dB −2.7, worse
No photo
PHL Audio2730
No current priceFs42 Hz −40%, better
Qts0.26 +4%
Vas34.1 L +87%, worse
BL12.6 T·m −12%, worse
Xmax7 mm +218%, better
Sensitivity91.7 dB −4.3, worse
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Lautsprecherteile | £58.97, the lowest price | 20 in stock | Visit shop at Lautsprecherteile |
Best price over time
Tracked since 1 Oct
