Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespLavoce CAN082.00K 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverCAN082 series
Lavoce
Lavoce CAN082.00K
Lavoce CAN082.00K is a 8" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 72Hz, Qts 0.27, Vas 15.1L, Xmax 6.7mm, sensitivity 94.8dB, plus 147cm³ Vd and 240 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
250W
Sensitivity
94.8dB
97.0dBmanufacturer; using T/S-derived value (2.2dB delta).
EBP
240
Vented alignment
Vd
147cm³
Overall Parameters
Valid
Fs72Hz
Qts0.27
Qes0.30
Qms3.5
Vas15.1L
Re5.1Ω
Le0.64mH
BL13.2Tm
Sd220cm²
Mms22g
Xmax6.7mm
SPL95dB
Power250W
Impedance8Ω
Min Impedance5.9Ω
F Low70Hz
F High20000Hz
Voice Coil51mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
What this validation status meansPricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.3kg
Driver Components
LF
Fs72 Hz
Qts0.27
Qes0.30
Qms3.5
Vas15.1 L
Re5.1 Ω
Le0.64 mH
BL13.2 Tm
Sd220 cm²
Mms22 g
Xmax6.7 mm
SPL95 dB
Power250 W
Impedance8 Ω
Min Impedance5.9 Ω
F Low70 Hz
F High3500 Hz
Voice Coil51 mm
Cms0.22
Power Program500
Xmech10.7
Section dimensions
Weight2300.0 kg
HF
SPL105 dB
Power50 W
Impedance8 Ω
Min Impedance7.4 Ω
F Low1200 Hz
F High20000 Hz
Xover1600 Hz
Throat25 mm
Voice Coil44 mm
Flux Density1.95 T
Power Program100
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Lavoce
CAN082.00K
8"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
89%
Similarity
£100.24
FaitalPRO
8PR210
8"
Xmax6.9mm+3%
Qts0.29+7%
BL13.5Tm+3%
Vas15.4L+2%
Qes0.32+7%
87%
Similarity
£225.53
B&C
8CXN51
8"
Xmax6mm-10%
Qts0.270%
BL12.6Tm-4%
Vas17L+13%
Qes0.29-3%
84%
Similarity
£75.85
Beyma
8WRS300
8"
Xmax6mm-10%
Qts0.28+4%
BL15.2Tm+16%
Vas15L0%
Qes0.30%
84%
Similarity
£90.56
Beyma
8WR300
8"
Xmax6mm-10%
Qts0.270%
BL15.5Tm+18%
Vas15L0%
Qes0.29-3%
82%
Similarity
£191.24
FaitalPRO
8HX230
8"
Xmax6.2mm-8%
Qts0.29+7%
BL15Tm+14%
Vas14.7L-2%
Qes0.31+3%
81%
Similarity
£231.79
FaitalPRO
8HX240
8"
Xmax6.2mm-8%
Qts0.3+11%
BL13.8Tm+5%
Vas12.9L-14%
Qes0.31+3%
80%
Similarity
Oberton
8MB201
8"
Xmax7mm+4%
Qts0.31+16%
BL12.5Tm-5%
Vas14.7L-2%
Qes0.33+10%
76%
Similarity
£121.64
B&C
8FG64
8"
Xmax7mm+4%
Qts0.31+15%
BL15.8Tm+20%
Vas15L0%
Qes0.32+7%
73%
Similarity
£62.00
FaitalPRO
8RS250
8"
Xmax6.9mm+3%
Qts0.32+19%
BL13.5Tm+3%
Vas18.3L+21%
Qes0.34+13%
71%
Similarity
£106.30
B&C
8FG51
8"
Xmax6.5mm-3%
Qts0.32+19%
BL12.9Tm-2%
Vas20L+33%
Qes0.34+13%
71%
Similarity
£219.76
FaitalPRO
8HX200
8"
Xmax4.9mm-27%
Qts0.3+11%
BL13.8Tm+5%
Vas13.1L-13%
Qes0.31+3%
71%
Similarity
Beyma
108CX3NDN8
8"
Xmax6mm-10%
Qts0.29+7%
BL12Tm-9%
Vas23L+53%
Qes0.30%
