Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespSica 8 C 2 CP 8Ω
LF DriverMedia
Auto-advancing
Overview
LF Driver
Sica
Sica 8 C 2 CP
Sica 8 C 2 CP is a 8" 8 ohm LF driver rated at 200W RMS. The validated T/S data includes Fs 79Hz, Qts 0.30, Vas 14.7L, Xmax 3.5mm, sensitivity 95.5dB, plus 75cm³ Vd and 245 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
200W
Sensitivity
95.5dB
96.7dBmanufacturer; using T/S-derived value (1.2dB delta).
EBP
245
Vented alignment
Vd
75cm³
T/S Parameters
Valid
Fs79Hz
Qts0.30
Qes0.32
Qms4.5
Vas14.7L
Re6.1Ω
Le0.80mH
BL13.5Tm
Sd214cm²
Mms18g
Xmax3.5mm
SPL96dB
Power200W
Impedance8Ω
Voice Coil50mm
Flux Density1.08T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.0kg
Diameter210.0mm
Overall Depth90.0mm
Cutout Diameter184.0mm
Bolt Circle Diameter196.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Sica
8 C 2 CP
8"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
95%
Similarity
Sica
8 N 2.5 PL
8"
Xmax3.5mm0%
Qts0.30%
BL12.9Tm-4%
Vas13.7L-7%
Qes0.33+3%
86%
Similarity
£128.21
PRV Audio
8MB700FT-NDY
8"
Xmax3.6mm+4%
Qts0.30%
BL12.8Tm-5%
Vas18.8L+28%
Qes0.33+3%
84%
Similarity
£171.89
BMS
8N515
8"
Xmax4mm+14%
Qts0.30%
BL13.8Tm+2%
Vas11L-25%
Qes0.320%
82%
Similarity
PRV Audio
8MB700FT
8"
Xmax3.5mm0%
Qts0.31+3%
BL12.3Tm-9%
Vas20L+36%
Qes0.33+3%
81%
Similarity
£133.32
Sica
8 FE 2.5 CP
8"
Xmax4mm+14%
Qts0.28-7%
BL13Tm-4%
Vas15.6L+6%
Qes0.3-6%
81%
Similarity
PRV Audio
8MR600X-NDY
8"
Xmax3.8mm+7%
Qts0.29-3%
BL15.2Tm+12%
Vas12.6L-14%
Qes0.3-6%
80%
Similarity
Sica
8 L 2 SL
8"
Xmax3.5mm0%
Qts0.32+7%
BL12.3Tm-9%
Vas18.2L+24%
Qes0.36+12%
79%
Similarity
£139.00
Celestion
FTX0820
8"
Xmax4mm+14%
Qts0.28-7%
BL14.6Tm+8%
Vas13.1L-11%
Qes0.31-3%
79%
Similarity
Monacor
FTX0820/8
8"
Xmax4mm+14%
Qts0.28-7%
BL14.6Tm+8%
Vas13.1L-11%
Qes0.31-3%
79%
Similarity
Jensen
BP8150-8
8"
Xmax3.1mm-11%
Qts0.33+10%
BL13.3Tm-2%
Vas13.1L-11%
Qes0.36+12%
78%
Similarity
£262.59
BMS
8CN552
8"
Xmax4mm+14%
Qts0.29-3%
BL13.4Tm0%
Vas10.1L-31%
Qes0.3-6%
77%
Similarity
CIARE
FXI8
8"
Xmax4.5mm+29%
Qts0.29-3%
BL13.3Tm-1%
Vas13L-12%
Qes0.320%
