REDCATT 8NPM 8Ω
8 Ω
No current price
- Fs
- 79Hz
- Xmax
- 3.7mm
- SPL
- 94dB
- Pe
- 200W
- BL
- 14.2T·m
- Vd
- 79cm³
- Qts
- 0.29
- Vas
- 11L
REDCATT 8NPM is an 8-inch 8 ohm LF driver rated at 200 W RMS. The validated T/S data includes Fs 79 Hz, Qts 0.29, Vas 10.9 L, Xmax 3.7 mm, sensitivity 94.4 dB, plus 79 cm³ Vd and 255 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 79Hz
- Qts
- 0.29
- Qes
- 0.31
- Qms
- 3.9
- Vas
- 10.9L
- Re
- 5.4Ω
- Le
- 0.60mH
Motor and cone
- BL
- 14.2T·m
- Sd
- 214cm²
- Mms
- 24g
- Xmax
- 3.7mm
- Vd †
- 79cm³
- Voice coil
- 51mm
Power and response
- Sensitivity †
- 94.4dB
- Manufacturer sensitivity
- 96.1dB
- Power
- 200W
- Impedance
- 8Ω
- EBP †
- 255 · Leans vented
Size and mounting
- Diameter
- 209.5mm
- Cutout
- 185mm
- Bolt circle
- 197.5mm
- Weight
- 1.8kg
Other published values
- Xmech
- 11.7
- Power Peak
- 800
Other dimensions
- Mounting Depth
- 87.3
Sensitivity shows 94.4 dB, calculated from the T/S values. REDCATT publishes 96.1 dB, 1.7 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 8″
- BL
- 14.2T·m
- Fs
- 79Hz
- Le
- 0.60mH
- Re
- 5.4Ω
- Sd
- 214cm²
- Mms
- 24g
- Qes
- 0.31
- Qms
- 3.9
- Qts
- 0.29
- SPL
- 94.4dB
- Vas
- 10.9L
- Xmax
- 3.7mm
- Xmech
- 11.7
- Power
- 200W
- Impedance
- 8Ω
- Power Peak
- 800
- Sensitivity
- 96.1dB
- Calculated sensitivity †
- 94.4dB
- Manufacturer sensitivity
- 96.1dB
- Voice coil
- 51mm
- Weight
- 1.8kg
- Diameter
- 209.5mm
- Mounting Depth
- 87.3
- Cutout
- 185mm
- Bolt circle
- 197.5mm
