T/S Parameters
Valid
Fs38Hz
Qts0.31
Qes0.33
Qms4.8
Vas19.0L
Re3.1Ω
Le1.40mH
BL11.8Tm
Sd219cm²
Mms62g
Xmax7.5mm
Power700W
Power Nominal350W
Impedance4Ω
F Low35Hz
F High2500Hz
Voice Coil75mm
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Weight5.0kg
Diameter224.0mm
Overall Depth101.5mm
Cutout Diameter184.0mm
Bolt Circle Diameter210.0mm
