Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespLavoce CAN123.00T 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverCAN123 series
Lavoce
Lavoce CAN123.00T
Lavoce CAN123.00T is a 12" 8 ohm LF driver rated at 350W RMS. The validated T/S data includes Fs 46Hz, Qts 0.22, Vas 91L, Xmax 6mm, sensitivity 97.9dB, plus 319cm³ Vd and 200 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
350W
Sensitivity
97.9dB
99.5dBmanufacturer; using T/S-derived value (1.6dB delta).
EBP
200
Vented alignment
Vd
319cm³
Overall Parameters
Valid
Fs46Hz
Qts0.22
Qes0.23
Qms4.0
Vas91.0L
Re5.3Ω
Le0.50mH
BL18.5Tm
Sd531cm²
Mms53g
Xmax6.0mm
SPL98dB
Power350W
Impedance8Ω
Min Impedance6.2Ω
F Low45Hz
F High18000Hz
Voice Coil75mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
What this validation status meansPricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.8kg
Driver Components
LF
Fs46 Hz
Qts0.22
Qes0.23
Qms4.0
Vas91.0 L
Re5.3 Ω
Le0.50 mH
BL18.5 Tm
Sd531 cm²
Mms53 g
Xmax6.0 mm
SPL98 dB
Power350 W
Impedance8 Ω
Min Impedance6.2 Ω
F Low45 Hz
F High3500 Hz
Voice Coil75 mm
Cms0.23
Power Program700
Xmech10
Section dimensions
Weight4800.0 kg
HF
SPL106 dB
Power80 W
Impedance8 Ω
Min Impedance8.0 Ω
F Low600 Hz
F High18000 Hz
Xover1200 Hz
Throat36 mm
Voice Coil75 mm
Flux Density1.90 T
Power Program160
