12-inch LF driver · CAN123 series · 75 mm voice coil · 350 W

Lavoce CAN123.00TH 8Ω

Name: Lavoce CAN123.00TH 8 Ohm
Brand: Lavoce
SKU: CAN123.00TH

8 Ω · 45–18000 Hz

No current price

View offers

Open in 00 Simulator

Fs: 46Hz
Xmax: 6mm
SPL: 98dB
Pe: 350W
BL: 18.5T·m
Vd: 319cm³
Qts: 0.22
Vas: 91L

See all 25 specs

Specifications

Published by Lavoce

Manufacturer page

Lavoce CAN123.00TH is a 12-inch 8 ohm LF driver rated at 350 W RMS. The validated T/S data includes Fs 46 Hz, Qts 0.22, Vas 91 L, Xmax 6 mm, sensitivity 97.9 dB, plus 319 cm³ Vd and 200 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 46Hz
Qts: 0.22
Qes: 0.23
Qms: 4
Vas: 91L
Re: 5.3Ω
Le: 0.50mH

Motor and cone

BL: 18.5T·m
Sd: 531cm²
Mms: 53g
Xmax: 6mm
Vd †: 319cm³
Voice coil: 75mm

Power and response

Sensitivity †: 97.9dB
Manufacturer sensitivity: 99.5dB
Power: 350W
Impedance: 8Ω
Min. impedance: 6.2Ω
Range: 45–18000Hz
EBP †: 200 · Leans vented

Size and mounting

Weight: 5kg

Other published values

Cms: 0.23mm/N
Xmech: 10
Power Program: 700
High limit: 3500Hz

Sensitivity shows 97.9 dB, calculated from the T/S values. Lavoce publishes 99.5 dB, 1.6 dB apart.

Excursion and motor values come from the LF section; the frequency range spans every section.

† Calculated by bits from the published values

What this validation status means

Components and manufacturer details

LF

BL: 18.5T·m
Fs: 46Hz
Le: 0.50mH
Re: 5.3Ω
Sd: 531cm²
Cms: 0.23mm/N
Mms: 53g
Qes: 0.23
Qms: 4
Qts: 0.22
SPL: 97.9dB
Vas: 91L
Xmax: 6mm
Xmech: 10
Power: 350W
Impedance: 8Ω
Sensitivity: 99.5dB
Low limit: 45Hz
Power Program: 700
Calculated sensitivity †: 97.9dB
High limit: 3500Hz
Manufacturer sensitivity: 99.5dB
Min. impedance: 6.2Ω
Voice coil: 75mm
Weight: 5kg

HF

SPL: 106dB
Power: 80W
Impedance: 8Ω
Flux density: 1.90T
Sensitivity: 106dB
Low limit: 600Hz
Power Program: 160
High limit: 18000Hz
Throat: 36mm
Manufacturer sensitivity: 106dB
Min. impedance: 8Ω
Voice coil: 75mm
Crossover: 1200Hz
