LF DriverLA series
Eminence
Eminence LA6-CBMR
Eminence LA6-CBMR is a 6" 8 ohm LF driver rated at 150W RMS. The validated T/S data includes Fs 460Hz, Qts 0.89, Vas 0.4L, Xmax 0.2mm, sensitivity 97dB, plus 3cm³ Vd and 371 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £69.00.
Size
6"
Impedance
8Ω
RMS Power
150W
Sensitivity
97.0dB
EBP
371
Vented alignment
Vd
3cm³
T/S Parameters
Valid
Fs460Hz
Qts0.89
Qes1.24
Qms3.1
Vas0.4L
Re6.3Ω
Le0.33mH
BL11.1Tm
Sd133cm²
Mms9g
Xmax0.2mm
SPL97dB
Power150W
Impedance8Ω
F Low500Hz
F High5000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£69.00
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.0kg
Overall Depth70.4mm
Cutout Diameter143.5mm
Bolt Circle Diameter153.9mm
