CIARE CXE174 4Ω
4 Ω
No price for delivery to the UK
- Fs
- 65Hz
- Xmax
- 2.1mm
- SPL
- 88dB
- Pe
- 75W
- BL
- 3.3T·m
- Vd
- 28cm³
- Qts
- 0.93
- Vas
- 15L
Manufacturer response and impedance data, with source and trace details below. The left and right arrow keys read every shown curve at a frequency, a twelfth of an octave at a time, or an octave with Shift. Escape clears the reading.
Curve provenanceInspect 2 traces
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v2
frequency response
Frequency response
240 plotted pointsSource file SHA-256 360b9f34bc7a…Medium confidence1,274 selected pixels of 1,274 - Trace datasheet-response-trace-poc/v2
free air impedance
Impedance response
240 plotted pointsSource file SHA-256 360b9f34bc7a…Medium confidence1,478 selected pixels of 1,478
CIARE CXE174 is a 6.5-inch 4 ohm LF driver rated at 75 W RMS. The validated T/S data includes Fs 65 Hz, Qts 0.93, Vas 15 L, Xmax 2.1 mm, sensitivity 87.5 dB, plus 28 cm³ Vd and 56 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 65Hz
- Qts
- 0.93
- Qes
- 1.17
- Qms
- 4.5
- Vas
- 15L
- Re
- 3.3Ω
Motor and cone
- BL
- 3.3T·m
- Sd
- 133cm²
- Mms
- 10g
- Xmax
- 2.1mm
- Vd †
- 28cm³
- Voice coil
- 25mm
Power and response
- Sensitivity †
- 87.5dB
- Manufacturer sensitivity
- 92dB
- Power
- 75W
- Nominal power
- 75W
- Impedance
- 4Ω
- EBP †
- 56 · Sealed or vented
Size and mounting
- Diameter
- 165mm
- Cutout
- 142mm
- Bolt circle
- 157mm
- Depth
- 66mm
- Weight
- 0.7kg
Other published values
- Cms
- 0.62mm/N
- Power Program
- 150
Sensitivity shows 87.5 dB, calculated from the T/S values. CIARE publishes 92.0 dB, 4.5 dB apart.
Excursion and motor values come from the LF section; the frequency range spans every section.
† Calculated by bits from the published values
What this validation status means
Components and manufacturer details
LF · Primary · 6.5″
- BL
- 3.3T·m
- Fs
- 65Hz
- Re
- 3.3Ω
- Sd
- 133cm²
- Cms
- 0.62mm/N
- Mms
- 10g
- Qes
- 1.17
- Qms
- 4.5
- Qts
- 0.93
- SPL
- 87.5dB
- Vas
- 15L
- Xmax
- 2.1mm
- Power
- 75W
- Impedance
- 4Ω
- Sensitivity
- 92dB
- Nominal power
- 75W
- Power Program
- 150
- Calculated sensitivity †
- 87.5dB
- Manufacturer sensitivity
- 92dB
- Voice coil
- 25mm
- Weight
- 0.7kg
- Diameter
- 165mm
- Depth
- 66mm
- Cutout
- 142mm
- Bolt circle
- 157mm
