Acoustic Elegance TD15S-8
Acoustic Elegance TD15S-8 is a 15" 8 ohm LF driver rated at 500W RMS. The validated T/S data includes Fs 23Hz, Qts 0.37, Vas 467L, Xmax 14mm, sensitivity 93.3dB, plus 1197cm³ Vd and 56 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
8Ω
RMS Power
500W
Sensitivity
93.3dB
EBP
56
Either alignment
Vd
1197cm³
T/S Parameters
Valid
Fs23Hz
Qts0.37
Qes0.41
Qms3.9
Vas467.0L
Re5.3Ω
Le0.30mH
BL14.1Tm
Sd855cm²
Mms108g
Xmax14.0mm
SPL93dB
Power500W
Power Nominal500W
Impedance8Ω
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
