Overview
LF DriverPAW series
Visaton
Visaton PAW 46
Visaton PAW 46 is a 15" 8 ohm LF driver rated at 700W RMS. The validated T/S data includes Fs 29Hz, Qts 0.36, Vas 325L, Xmax 10mm, sensitivity 95.2dB, plus 1210cm³ Vd and 76 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
8Ω
RMS Power
700W
Sensitivity
95.2dB
93.0dBmanufacturer; using T/S-derived value (2.2dB delta).
EBP
76
Either alignment
Vd
1210cm³
T/S Parameters
Valid
Fs29Hz
Qts0.36
Qes0.38
Qms9.0
Vas325.0L
Re6.1Ω
Le1.50mH
BL23.6Tm
Sd1210cm²
Mms186g
Xmax10.0mm
SPL95dB
Power700W
Impedance8Ω
F High3200Hz
Voice Coil100mm
Pricing & availability
Price definitionsVendor offers
1 vendorsoundimports
Updated 11 Sept 2026· 8Ω
Source: inc VAT
£317.85
inc VAT
Out of stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight11.5kg
Diameter460.0mm
Cutout Diameter422.0mm
