Overview
LF DriverTIW series
Visaton
Visaton TIW 200 XS
Visaton TIW 200 XS is a 8" 8 ohm LF driver rated at 120W RMS. The validated T/S data includes Fs 30Hz, Qts 0.46, Vas 51.5L, Xmax 12.5mm, sensitivity 86.5dB, plus 258cm³ Vd and 60 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
120W
Sensitivity
86.5dB
84.0dBmanufacturer; using T/S-derived value (2.5dB delta).
EBP
60
Either alignment
Vd
258cm³
T/S Parameters
Valid
Fs30Hz
Qts0.46
Qes0.50
Qms5.2
Vas51.5L
Re6.0Ω
Le1.60mH
BL8.5Tm
Sd206cm²
Mms33g
Xmax12.5mm
SPL87dB
Power120W
Impedance8Ω
F High7500Hz
Voice Coil38mm
Flux Density1.10T
Pricing & availability
Price definitionsVendor offers
1 vendorsoundimports
Updated 11 Sept 2026
Source: inc VAT
£150.31
inc VAT
Out of stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.5kg
Diameter200.0mm
Cutout Diameter190.0mm
