LF DriverRevelator series
Scanspeak
Scanspeak 32W/8878T11
Scanspeak 32W/8878T11 is a 12" 8 ohm LF driver rated at 350W RMS. The validated T/S data includes Fs 21Hz, Qts 0.26, Vas 235L, Xmax 7.5mm, sensitivity 90.9dB, plus 395cm³ Vd and 75 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
350W
Sensitivity
90.9dB
EBP
75
Either alignment
Vd
395cm³
T/S Parameters
Valid
Fs21Hz
Qts0.26
Qes0.28
Qms3.8
Vas235.0L
Re6.1Ω
Le0.60mH
BL16.5Tm
Sd526cm²
Mms96g
Xmax7.5mm
SPL91dB
Power350W
Impedance8Ω
Min Impedance7.2Ω
Voice Coil75mm
Pricing & availability
Price definitionsNo current price found
Pricing may appear after the next vendor refresh.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter320.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Scanspeak
32W/8878T11
12"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
72%
Similarity
Dayton Audio
APOLLO 12N
12"
Xmax6.8mm-10%
Qts0.260%
BL19.2Tm+16%
Vas128.1L-45%
Qes0.27-4%
71%
Similarity
Scanspeak
32W/4878T01
12"
Xmax7mm-7%
Qts0.28+8%
BL13Tm-21%
Vas170L-28%
Qes0.3+7%
67%
Similarity
Audio Technology
12 D 77 25 10 KAP
12"
Xmax8.6mm+15%
Qts0.25-4%
BL14Tm-15%
Vas340L+45%
Qes0.26-7%
66%
Similarity
Scanspeak
28W/4878T01
12"
Xmax7mm-7%
Qts0.260%
BL12Tm-27%
Vas104L-56%
Qes0.27-4%
65%
Similarity
PRV Audio
12MB1000FT-4
12"
Xmax6.1mm-18%
Qts0.27+4%
BL14.5Tm-12%
Vas95.5L-59%
Qes0.280%
62%
Similarity
Scanspeak
28W/8878T01
12"
Xmax7.5mm0%
Qts0.31+19%
BL14.9Tm-10%
Vas116L-51%
Qes0.33+18%
60%
Similarity
Scanspeak
32W/4878T11
12"
Xmax7mm-7%
Qts0.21-19%
BL14Tm-15%
Vas185L-21%
Qes0.22-21%
60%
Similarity
Audio Technology
12 B 77 25 10
12"
Xmax8.6mm+15%
Qts0.3+15%
BL12.4Tm-25%
Vas250L+6%
Qes0.34+21%
57%
Similarity
£337.46
Beyma
12CXA400FE
12"
Xmax6mm-20%
Qts0.25-4%
BL19.8Tm+20%
Vas94L-60%
Qes0.26-7%
54%
Similarity
£120.00
RCF
LF12G301
12"
Xmax7mm-7%
Qts0.22-15%
BL19Tm+15%
Vas97L-59%
Qes0.23-18%
54%
Similarity
RCF
LF12G801
12"
Xmax7mm-7%
Qts0.22-15%
BL19Tm+15%
Vas97L-59%
Qes0.23-18%
54%
Similarity
RCF
LF12P901
12"
Xmax7mm-7%
Qts0.22-15%
BL19Tm+15%
Vas97L-59%
Qes0.23-18%
