Lavoce WAN123.00 8Ω
8 Ω · 50–3000 Hz
£163.28
SteadyBlue Aran · 2 in stock · All 3 offers
- Fs
- 49Hz
- Xmax
- 6.9mm
- SPL
- 97dB
- Pe
- 500W
- BL
- 17.9T·m
- Vd
- 366cm³
- Qts
- 0.27
- Vas
- 69L
Lavoce WAN123.00 is a 12-inch 8 ohm LF driver rated at 500 W RMS. The validated T/S data includes Fs 49 Hz, Qts 0.27, Vas 68.8 L, Xmax 6.9 mm, sensitivity 96.6 dB, plus 366 cm³ Vd and 175 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £163.28.
The published T/S values agree with each other
Thiele/Small
- Fs
- 49Hz
- Qts
- 0.27
- Qes
- 0.28
- Qms
- 6.5
- Vas
- 68.8L
- Re
- 4.8Ω
- Le
- 0.69mH
Motor and cone
- BL
- 17.9T·m
- Sd
- 531cm²
- Mms
- 62g
- Xmax
- 6.9mm
- Vd †
- 366cm³
- Voice coil
- 75mm
Power and response
- Sensitivity †
- 96.6dB
- Manufacturer sensitivity
- 99dB
- Power
- 500W
- Impedance
- 8Ω
- Min. impedance
- 5.7Ω
- Range
- 50–3000Hz
- EBP †
- 175 · Leans vented
Size and mounting
- Weight
- 5.2kg
Other published values
- Cms
- 0.17mm/N
- Xmech
- 12.7
- Power Program
- 1000
Sensitivity shows 96.6 dB, calculated from the T/S values. Lavoce publishes 99.0 dB, 2.4 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 12″
- BL
- 17.9T·m
- Fs
- 49Hz
- Le
- 0.69mH
- Re
- 4.8Ω
- Sd
- 531cm²
- Cms
- 0.17mm/N
- Mms
- 62g
- Qes
- 0.28
- Qms
- 6.5
- Qts
- 0.27
- SPL
- 96.6dB
- Vas
- 68.8L
- Xmax
- 6.9mm
- Xmech
- 12.7
- Power
- 500W
- Impedance
- 8Ω
- Sensitivity
- 99dB
- Low limit
- 50Hz
- Power Program
- 1000
- Calculated sensitivity †
- 96.6dB
- High limit
- 3000Hz
- Manufacturer sensitivity
- 99dB
- Min. impedance
- 5.7Ω
- Voice coil
- 75mm
- Weight
- 5.2kg
