LF Driver
Eighteen Sound
Eighteen Sound 18LW1251
Eighteen Sound 18LW1251 is a 18" 8 ohm LF driver rated at 1000W RMS. The validated T/S data includes Fs 35Hz, Qts 0.27, Vas 268L, Xmax 9mm, sensitivity 98.2dB, plus 1021cm³ Vd and 125 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £250.53.
Size
18"
Impedance
8Ω
RMS Power
1000W
Sensitivity
98.2dB
EBP
125
Vented alignment
Vd
1021cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
frequency response240 ptsp2medium
Curve provenanceInspect 2 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
frequency response
Frequency response
240 plotted pointsMedium confidence2,198 selected pixels of 2,424 - Trace datasheet-response-trace-poc/v1
impedance
Impedance response
240 plotted pointsMedium confidence1,661 selected pixels of 1,755
T/S Parameters
Valid
Fs35Hz
Qts0.27
Qes0.28
Qms8.0
Vas268.0L
Re5.0Ω
Le2.73mH
BL23.6Tm
Sd1134cm²
Mms142g
Xmax9.0mm
SPL98dB
Power1000W
Power Nominal1000W
Impedance8Ω
F Low35Hz
F High3500Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£250.53
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight13.0kg
Diameter462.0mm
Overall Depth207.0mm
Cutout Diameter416.0mm
Bolt Circle Diameter438.0mm
