Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespMedia
Auto-advancing
Overview
LF Driver18XB series
Oberton
Oberton 18XB1600v2
Oberton 18XB1600v2 is a 18" 8 ohm LF driver rated at 1600W RMS. The validated T/S data includes Fs 33Hz, Qts 0.28, Vas 267L, Xmax 12.5mm, sensitivity 97.1dB, plus 1448cm³ Vd and 113 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £388.58.
Size
18"
Impedance
8Ω
RMS Power
1600W
Sensitivity
97.1dB
EBP
113
Vented alignment
Vd
1448cm³
T/S Parameters
Valid
Fs33Hz
Qts0.28
Qes0.29
Qms8.7
Vas267.0L
Re5.3Ω
Le1.46mH
BL29.6Tm
Sd1158cm²
Mms231g
Xmax12.5mm
SPL97dB
Power1600W
Impedance8Ω
Min Impedance6.7Ω
F Low35Hz
F High1000Hz
Voice Coil115mm
Flux Density1.10T
Pricing & availability
Price definitionsPrice movement
Best current price
£388.58
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight18.2kg
Diameter462.0mm
Overall Depth207.5mm
Cutout Diameter410.0mm
Bolt Circle Diameter441.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Oberton
18XB1600v2
18"
Best current price
£388.58
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
71%
Similarity
44% cheaper£215.75
RCF
LF18G401
18"
Lower price
Xmax9mm-28%
Qts0.29+4%
BL24.6Tm-17%
Vas268L0%
Qes0.3+5%
52%
Similarity
42% cheaper£226.82
FaitalPRO
18FH510
18"
Lower price
Xmax9.3mm-26%
Qts0.29+4%
BL21Tm-29%
Vas411.9L+54%
Qes0.3+5%
69%
Similarity
41% cheaper£229.00
FaitalPRO
18HP1022
18"
Lower price
Xmax9.5mm-24%
Qts0.3+8%
BL28Tm-5%
Vas204.9L-23%
Qes0.31+8%
57%
Similarity
38% cheaper£238.99
B&C
18TBX100
18"
Lower price
Xmax9mm-28%
Qts0.31+12%
BL22Tm-26%
Vas256L-4%
Qes0.33+15%
84%
Similarity
37% cheaper£244.93
RCF
LF18X401
18"
Lower price
Xmax12mm-4%
Qts0.3+8%
BL26.5Tm-10%
Vas274L+3%
Qes0.31+8%
68%
Similarity
37% cheaper£245.00
RCF
L18P400
18"
Lower price
Xmax9mm-28%
Qts0.28+1%
BL24.6Tm-17%
Vas340L+27%
Qes0.29+1%
72%
Similarity
36% cheaper£250.53
Eighteen Sound
18LW1251
18"
Lower price
Xmax9mm-28%
Qts0.27-3%
BL23.6Tm-20%
Vas268L0%
Qes0.28-2%
60%
Similarity
31% cheaper£268.99
B&C
18TBW100
18"
Lower price
Xmax12mm-4%
Qts0.32+15%
BL22.8Tm-23%
Vas181.5L-32%
Qes0.34+18%
67%
Similarity
30% cheaper£270.47
Eighteen Sound
18LW1400
18"
Lower price
Xmax9mm-28%
Qts0.29+4%
BL24.7Tm-17%
Vas297L+11%
Qes0.31+8%
64%
Similarity
30% cheaper£272.63
Eighteen Sound
18LW2400
18"
Lower price
Xmax9.5mm-24%
Qts0.31+12%
BL25.6Tm-14%
Vas230L-14%
Qes0.32+11%
81%
Similarity
30% cheaper£273.68
Beyma
18PW1400FE
18"
Lower price
Xmax10mm-20%
Qts0.27-3%
BL29Tm-2%
Vas228.9L-14%
Qes0.28-2%
73%
Similarity
29% cheaper£277.00
B&C
18NW100
18"
Lower price
Xmax9mm-28%
Qts0.26-6%
BL28Tm-5%
Vas252L-6%
Qes0.27-6%
