Overview
LF DriverCSW series
CIARE
CIARE CSW7115EVO
CIARE CSW7115EVO is a 15" 1 ohm LF driver rated at 3000W RMS. The validated T/S data includes Fs 42Hz, Qts 0.44, Vas 36L, Xmax 22mm, sensitivity 89.7dB, plus 1826cm³ Vd and 91 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
1Ω
RMS Power
3000W
Sensitivity
89.7dB
96.0dBmanufacturer; using T/S-derived value (6.3dB delta).
EBP
91
Either alignment
Vd
1826cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
frequency response240 ptsp1medium
Curve provenanceInspect 1 traceHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
frequency response
Frequency response
240 plotted pointsMedium confidence1,459 selected pixels of 1,660
T/S Parameters
Valid
Fs42Hz
Qts0.44
Qes0.46
Qms7.7
Vas36.0L
Re1.8Ω
Le1.18mH
BL20.1Tm
Sd830cm²
Mms399g
Xmax22.0mm
SPL90dB
Power3000W
Power Nominal700W
Impedance1Ω
F Low25Hz
F High200Hz
Voice Coil75mm
Pricing & availability
Price definitionsVendor offers
1 vendorleanaudio
Updated 11 Sept 2026
Source: inc VAT · 20%
£523.72
inc VAT
Back order
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight19.6kg
Diameter388.0mm
Overall Depth239.0mm
Cutout Diameter350.0mm
Bolt Circle Diameter368.0mm
