Overview
LF DriverW series
Visaton
Visaton W 200
Visaton W 200 is a 8" 4 ohm LF driver rated at 50W RMS. The validated T/S data includes Fs 45Hz, Qts 0.63, Vas 54L, Xmax 10mm, sensitivity 90.1dB, plus 207cm³ Vd and 58 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
4Ω
RMS Power
50W
Sensitivity
90.1dB
88.0dBmanufacturer; using T/S-derived value (2.1dB delta).
EBP
58
Either alignment
Vd
207cm³
T/S Parameters
Valid
Fs45Hz
Qts0.63
Qes0.77
Qms3.5
Vas54.0L
Re3.2Ω
Le0.50mH
BL4.2Tm
Sd207cm²
Mms14g
Xmax10.0mm
SPL90dB
Power50W
Impedance4Ω
F High8000Hz
Voice Coil25mm
Flux Density1.00T
Pricing & availability
Price definitionsVendor offers
1 vendorsoundimports
Updated 11 Sept 2026· 4Ω
Source: inc VAT
£28.31
inc VAT
Out of stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.0kg
Diameter200.0mm
Cutout Diameter185.0mm
