6-inch LF driver · 50 mm voice coil · 200 W
Sica 6 CX 2 PL P 8Ω
8 Ω
No current price
- Fs
- 85Hz
- Xmax
- 3.5mm
- SPL
- 93dB
- Pe
- 200W
- BL
- 12.8T·m
- Vd
- 43cm³
- Qts
- 0.24
- Vas
- 5L
Sica 6 CX 2 PL P is a 6-inch 8 ohm LF driver rated at 200 W RMS. The validated T/S data includes Fs 85 Hz, Qts 0.24, Vas 5.4 L, Xmax 3.5 mm, sensitivity 92.9 dB, plus 43 cm³ Vd and 315 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 85Hz
- Qts
- 0.24
- Qes
- 0.27
- Qms
- 2.4
- Vas
- 5.4L
- Re
- 6Ω
- Le
- 0.70mH
Motor and cone
- BL
- 12.8T·m
- Sd
- 123cm²
- Mms
- 14g
- Xmax
- 3.5mm
- Vd †
- 43cm³
- Voice coil
- 50mm
Power and response
- Sensitivity †
- 92.9dB
- Manufacturer sensitivity
- 94.2dB
- Power
- 200W
- Impedance
- 8Ω
- EBP †
- 315 · Leans vented
Size and mounting
- Diameter
- 166mm
- Cutout
- 143mm
- Bolt circle
- 155mm
- Depth
- 104.1mm
- Weight
- 1.8kg
Other published values
- Cms
- 0.25mm/N
- Power Program
- 400
Sensitivity shows 92.9 dB, calculated from the T/S values. Sica publishes 94.2 dB, 1.3 dB apart.
Excursion and motor values come from the LF section; the frequency range spans every section.
† Calculated by bits from the published values
What this validation status means
Components and manufacturer details
LF · LF · 6″
- BL
- 12.8T·m
- Fs
- 85Hz
- Le
- 0.70mH
- Re
- 6Ω
- Sd
- 123cm²
- Cms
- 0.25mm/N
- Mms
- 14g
- Qes
- 0.27
- Qms
- 2.4
- Qts
- 0.24
- SPL
- 92.9dB
- Vas
- 5.4L
- Xmax
- 3.5mm
- Power
- 200W
- Impedance
- 8Ω
- Sensitivity
- 94.2dB
- Power Program
- 400
- Calculated sensitivity †
- 92.9dB
- Manufacturer sensitivity
- 94.2dB
- Voice coil
- 50mm
HF · HF
- Fs
- 700Hz
- Re
- 6Ω
- SPL
- 102.7dB
- Power
- 60W
- Impedance
- 8Ω
- Sensitivity
- 102.7dB
- Power Program
- 120
- Manufacturer sensitivity
- 102.7dB
- Voice coil
- 44mm
- Crossover
- 1600Hz
