18-inch LF driver · SAF184 series · 100 mm voice coil · 1,500 W
Lavoce SAF184.04 8Ω
8 Ω · 35–1000 Hz
No price for delivery to the UK
- Fs
- 38Hz
- Xmax
- 12.5mm
- SPL
- 94dB
- Pe
- 1500W
- BL
- 26.5T·m
- Vd
- 1525cm³
- Qts
- 0.50
- Vas
- 135L
Lavoce SAF184.04 is an 18-inch 8 ohm LF driver rated at 1500 W RMS. The validated T/S data includes Fs 38 Hz, Qts 0.50, Vas 134.8 L, Xmax 12.5 mm, sensitivity 93.5 dB, plus 1525 cm³ Vd and 72 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £225.48.
The published T/S values agree with each other
Thiele/Small
- Fs
- 38Hz
- Qts
- 0.50
- Qes
- 0.53
- Qms
- 7.7
- Vas
- 134.8L
- Re
- 5.7Ω
- Le
- 1.90mH
Motor and cone
- BL
- 26.5T·m
- Sd
- 1220cm²
- Mms
- 276g
- Xmax
- 12.5mm
- Vd †
- 1525cm³
- Voice coil
- 100mm
Power and response
- Sensitivity †
- 93.5dB
- Manufacturer sensitivity
- 95dB
- Power
- 1500W
- Impedance
- 8Ω
- Min. impedance
- 6.8Ω
- Range
- 35–1000Hz
- EBP †
- 72 · Sealed or vented
Size and mounting
- Weight
- 16.1kg
Other published values
- Cms
- 0.064mm/N
- Xmech
- 21.7
- Power Program
- 3000
Sensitivity shows 93.5 dB, calculated from the T/S values. Lavoce publishes 95.0 dB, 1.5 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 18″
- BL
- 26.5T·m
- Fs
- 38Hz
- Le
- 1.90mH
- Re
- 5.7Ω
- Sd
- 1220cm²
- Cms
- 0.064mm/N
- Mms
- 276g
- Qes
- 0.53
- Qms
- 7.7
- Qts
- 0.50
- SPL
- 93.5dB
- Vas
- 134.8L
- Xmax
- 12.5mm
- Xmech
- 21.7
- Power
- 1500W
- Impedance
- 8Ω
- Sensitivity
- 95dB
- Low limit
- 35Hz
- Power Program
- 3000
- Calculated sensitivity †
- 93.5dB
- High limit
- 1000Hz
- Manufacturer sensitivity
- 95dB
- Min. impedance
- 6.8Ω
- Voice coil
- 100mm
- Weight
- 16.1kg
