Overview
LF Driver
Fane
Fane IMPERIUM 18XL
Fane IMPERIUM 18XL is a 18" 8 ohm LF driver rated at 1300W RMS. The validated T/S data includes Fs 36Hz, Qts 0.53, Vas 205L, Xmax 10.5mm, sensitivity 94.4dB, plus 1191cm³ Vd and 64 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
18"
Impedance
8Ω
RMS Power
1300W
Sensitivity
94.4dB
96.0dBmanufacturer; using T/S-derived value (1.6dB delta).
EBP
64
Either alignment
Vd
1191cm³
T/S Parameters
Valid
Fs36Hz
Qts0.53
Qes0.56
Qms11.1
Vas205.0L
Re5.9Ω
Le2.90mH
BL20.4Tm
Sd1134cm²
Mms174g
Xmax10.5mm
SPL94dB
Power1300W
Impedance8Ω
F Low30Hz
F High2000Hz
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight28.9kg
Diameter485.1mm
Overall Depth201.7mm
