Overview
LF Driver
GRS
GRS 18PT-8
GRS 18PT-8 is a 18" 8 ohm LF driver rated at 350W RMS. The validated T/S data includes Fs 23Hz, Qts 0.54, Vas 16.8L, Xmax 7.8mm, sensitivity 77.5dB, plus 963cm³ Vd and 40 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £63.60.
Size
18"
Impedance
8Ω
RMS Power
350W
Sensitivity
77.5dB
93.0dBmanufacturer; using T/S-derived value (15.5dB delta).
EBP
40
Sealed alignment
Vd
963cm³
T/S Parameters
Valid
Fs23Hz
Qts0.54
Qes0.58
Qms9.6
Vas16.8L
Re6.9Ω
Le1.90mH
BL19.5Tm
Sd1234cm²
Mms218g
Xmax7.8mm
SPL78dB
Power350W
Impedance8Ω
F Low25Hz
F High4000Hz
Voice Coil76mm
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorsoundimports
Updated 11 Sept 2026· 8Ω
Source: inc VAT
£111.65
inc VAT
Out of stock
Best current price
Updated 11 Sept 2026
partsexpress
£63.60
inc VAT·199 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter408.2mm
Overall Depth190.0mm
Cutout Diameter422.9mm
Bolt Circle Diameter446.8mm
