Overview
LF DriverROSSO series
SB Audience
SB Audience ROSSO-18SW1000D
SB Audience ROSSO-18SW1000D is a 18" 5.2 ohm LF driver rated at 2000W RMS. The validated T/S data includes Fs 35Hz, Qts 0.46, Vas 164.3L, Xmax 13.7mm, sensitivity 93.6dB, plus 1718cm³ Vd and 71 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
18"
Impedance
5.2Ω
RMS Power
2000W
Sensitivity
93.6dB
EBP
71
Either alignment
Vd
1718cm³
T/S Parameters
Valid
Fs35Hz
Qts0.46
Qes0.49
Qms10.1
Vas164.3L
Re5.3Ω
Le1.64mH
BL25.8Tm
Sd1257cm²
Mms276g
Xmax13.7mm
SPL94dB
Power2000W
Impedance5Ω
Pricing & availability
Price definitionsNo current price found
Pricing may appear after the next vendor refresh.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
SB Audience
ROSSO-18SW1000D
18"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
89%
Similarity
Peerless
FCP-1840R02-08
18"
Xmax13.5mm-1%
Qts0.43-7%
BL26.2Tm+2%
Vas156L-5%
Qes0.44-9%
85%
Similarity
Peerless
FCP-1840R03-08
18"
Xmax12.3mm-10%
Qts0.47+2%
BL26.8Tm+4%
Vas128L-22%
Qes0.49-1%
78%
Similarity
£239.00
Celestion
CF1840JD
18"
Xmax12.5mm-9%
Qts0.4-14%
BL24.8Tm-4%
Vas155L-6%
Qes0.44-11%
78%
Similarity
Monacor
CF1840JD/4
18"
Xmax12.5mm-9%
Qts0.4-14%
BL24.8Tm-4%
Vas155L-6%
Qes0.44-11%
78%
Similarity
Monacor
CF1840JD/8
18"
Xmax12.5mm-9%
Qts0.4-14%
BL24.8Tm-4%
Vas155L-6%
Qes0.44-11%
76%
Similarity
£269.00
FaitalPRO
18HP1030
18"
Xmax12.4mm-9%
Qts0.41-11%
BL24.3Tm-6%
Vas185.5L+13%
Qes0.43-12%
75%
Similarity
Beyma
118LEX16ND8
18"
Xmax14.5mm+6%
Qts0.43-7%
BL24.5Tm-5%
Vas231L+41%
Qes0.45-8%
74%
Similarity
£341.86
Eighteen Sound
18TLW3000
18"
Xmax12mm-12%
Qts0.41-11%
BL24.5Tm-5%
Vas185L+13%
Qes0.42-14%
73%
Similarity
£268.99
B&C
18TBW100
18"
Xmax12mm-12%
Qts0.39-15%
BL26.4Tm+2%
Vas175L+7%
Qes0.41-16%
72%
Similarity
£235.00
B&C
18SW100
18"
Xmax12.5mm-9%
Qts0.38-17%
BL26.1Tm+1%
Vas180L+10%
Qes0.4-18%
72%
Similarity
£277.00
Beyma
18LEX1600FE
18"
Xmax13mm-5%
Qts0.38-17%
BL26.9Tm+4%
Vas188L+14%
Qes0.4-18%
69%
Similarity
£325.00
FaitalPRO
18HW1070
18"
Xmax13mm-5%
Qts0.38-17%
BL27Tm+5%
Vas195.9L+19%
Qes0.39-20%
