Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespDayton Audio DC130AS-8 8Ω
LF DriverMedia
Auto-advancing
Overview
LF Driver
Dayton Audio
Dayton Audio DC130AS-8
Dayton Audio DC130AS-8 is a 4" 8 ohm LF driver rated at 30W RMS. The validated T/S data includes Fs 57Hz, Qts 0.45, Vas 9.7L, Xmax 2.5mm, sensitivity 87dB, plus 23cm³ Vd and 99 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £22.17.
Size
4"
Impedance
8Ω
RMS Power
30W
Sensitivity
87.0dB
88.5dBmanufacturer; using T/S-derived value (1.5dB delta).
EBP
99
Either alignment
Vd
23cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
15 degrees220 ptsp1medium
30 degrees220 ptsp1medium
45 degrees232 ptsp1medium
Curve provenanceInspect 4 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
15 degrees
Frequency response
220 plotted pointsMedium confidence705 selected pixels of 856 - Trace datasheet-response-trace-poc/v1
30 degrees
Frequency response
220 plotted pointsMedium confidence549 selected pixels of 1,074 - Trace datasheet-response-trace-poc/v1
45 degrees
Frequency response
232 plotted pointsMedium confidence715 selected pixels of 1,172 - Trace datasheet-response-trace-poc/v1
impedance
Impedance response
240 plotted pointsMedium confidence1,063 selected pixels of 1,063
T/S Parameters
Valid
Fs57Hz
Qts0.45
Qes0.58
Qms2.0
Vas9.7L
Re5.6Ω
Le0.84mH
BL5.8Tm
Sd92cm²
Mms10g
Xmax2.5mm
SPL87dB
Power30W
Impedance8Ω
F Low55Hz
F High4000Hz
Pricing & availability
Price definitionsPrice movement
Other offers
2 vendorssoundimports
Updated 11 Sept 2026· 8Ω
Source: inc VAT
£29.17
inc VAT
Out of stock
wilmslowaudio
Updated 11 Sept 2026· 8Ω
Source: inc VAT · 20%
£48.00
inc VAT
Best current price
Updated 11 Sept 2026
partsexpress
£22.17
Avg £35.09£12.91 below avg (-36.8%)
inc VAT·121 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.1kg
Diameter134.0mm
Overall Depth78.4mm
Cutout Diameter120.0mm
