Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespVisaton W 130 S 4Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverW series
Visaton
Visaton W 130 S
Visaton W 130 S is a 5" 4 ohm LF driver rated at 50W RMS. The validated T/S data includes Fs 50Hz, Qts 0.45, Vas 14L, Xmax 8mm, sensitivity 87.1dB, plus 59cm³ Vd and 91 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £37.14.
Size
5"
Impedance
4Ω
RMS Power
50W
Sensitivity
87.1dB
EBP
91
Either alignment
Vd
59cm³
T/S Parameters
Valid
Fs50Hz
Qts0.45
Qes0.55
Qms2.5
Vas14.0L
Re3.5Ω
Le0.60mH
BL3.6Tm
Sd74cm²
Mms5g
Xmax8.0mm
SPL87dB
Power50W
Impedance4Ω
F High12000Hz
Voice Coil25mm
Flux Density0.90T
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorsoundimports
Updated 11 Sept 2026· 4Ω
Source: inc VAT
£33.04
inc VAT
Out of stock
Best current price
Updated 8 Sept 2026
impactaudio
£37.14
inc VAT·In stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.6kg
Diameter130.0mm
Cutout Diameter109.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Visaton
W 130 S
5"
Best current price
£37.14
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
6 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
32%
Similarity
23% cheaper£28.74
Visaton
KT 100 V
4"
Lower price
Xmax7mm-12%
Qts0.56+24%
BL3.3Tm-8%
Vas7.5L-46%
Qes0.69+25%
77%
Similarity
£37.14
Visaton
W 130 S - 8 Ohm
5"
Xmax8mm0%
Qts0.47+4%
BL4.6Tm+28%
Vas12L-14%
Qes0.59+7%
38%
Similarity
22% more£45.28
SB Acoustics
SB12NRX25-4
4"
Higher price
Xmax10mm+25%
Qts0.4-11%
BL3.6Tm0%
Vas5.6L-60%
Qes0.46-16%
100%
Similarity
Visaton
W 130 S - 4 OHM
5"
Xmax8mm0%
Qts0.450%
BL3.6Tm0%
Vas14L0%
Qes0.550%
66%
Similarity
Tang Band
W5-1685
5"
Xmax6mm-25%
Qts0.46+2%
BL4.7Tm+31%
Vas12.8L-9%
Qes0.53-4%
32%
Similarity
Visaton
KT 100 V - 4 OHM
4"
Xmax7mm-12%
Qts0.56+24%
BL3.3Tm-8%
Vas7.5L-46%
Qes0.69+25%
