6-inch LF driver · Flexunits series · 180 W

Audio Technology 6 A 77 20 06 SD 8Ω

Name: Audio Technology 6 A 77 20 06 SD 8 Ohm
Brand: Audio Technology
SKU: 6 A 77 20 06 SD

8 Ω

No current price

View offers

Open in 00 Simulator

Fs: 34Hz
Xmax: 8mm
SPL: 89dB
Pe: 180W
BL: 8T·m
Vd: 138cm³
Qts: 0.32
Vas: 44L

See all 20 specs

Specifications

Published by Audio Technology

Manufacturer page

Datasheet PDF

Audio Technology 6 A 77 20 06 SD is a 6-inch 8 ohm LF driver rated at 180 W RMS. The validated T/S data includes Fs 34 Hz, Qts 0.32, Vas 44 L, Xmax 8 mm, sensitivity 88.6 dB, plus 138 cm³ Vd and 89 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 34Hz
Qts: 0.32
Qes: 0.38
Qms: 2
Vas: 44L
Re: 5.5Ω
Le: 0.18mH

Motor and cone

BL: 8T·m
Sd: 172cm²
Mms: 21g
Xmax: 8mm
Vd †: 138cm³

Power and response

Sensitivity †: 88.6dB
Manufacturer sensitivity: 88.5dB
Power: 180W
Impedance: 8Ω
EBP †: 89 · Sealed or vented

Other published values

Cms: 1.04mm/N
Rms: 2.24kg/s
Xmech: 35

† Calculated by bits from the published values

What this validation status means

Everything else Audio Technology lists

LF · Primary · 6″

BL: 8T·m
Fs: 34Hz
Le: 0.18mH
Re: 5.5Ω
Sd: 172cm²
Cms: 1.04mm/N
Mms: 21g
Qes: 0.38
Qms: 2
Qts: 0.32
Rms: 2.24kg/s
SPL: 88.6dB
Vas: 44L
Xmax: 8mm
Xmech: 35
Power: 180W
Impedance: 8Ω
Sensitivity: 88.5dB
Calculated sensitivity †: 88.6dB
Manufacturer sensitivity: 88.5dB

Compare

Same-size drivers, compared with the 6 A 77 20 06 SD. Clear differences are green when better and red when worse.

This driver6 A 77 20 06 SD

Best price

–

34 Hz

Qts

0.32

Vas

44 L

8 T·m

Xmax

8 mm

Sensitivity

88.6 dB

Power

180 W

SB AcousticsSB15SFCR39-4

£40.19

Fs31 Hz −9%

Qts0.32 –

Vas49.9 L +13%

BL6.9 T·m −14%

Xmax11 mm +38%

Sensitivity88.4 dB –

CIAREHW162

£48.28

Fs44 Hz +29%

Qts0.33 +3%

Vas24.8 L −44%

BL7.5 T·m −6%

Xmax4.5 mm −44%

Sensitivity89.4 dB +0.8

Dayton AudioRS180-8

£60.56

Fs36 Hz +5%

Qts0.31 −3%

Vas24.4 L −45%

BL7.8 T·m –

Xmax6 mm −25%

Sensitivity86.3 dB −2.3

HiViE6.5

£64.34

Fs37 Hz +9%

Qts0.32 –

Vas31 L −30%

BL8.1 T·m –

Xmax5.8 mm −28%

Sensitivity88.3 dB –

SEASH1215-08 CA18RNX

£109.59

Fs35 Hz –

Qts0.31 −3%

Vas33 L −25%

BL7.2 T·m −10%

Xmax6 mm −25%

Sensitivity87.9 dB −0.7

SEASH1456-08 ER18RNX

£110.55

Fs37 Hz +9%

Qts0.32 –

Vas32 L −27%

BL7.2 T·m −10%

Xmax6 mm −25%

Sensitivity88.2 dB –

WavecorWF182BD12

£119.63

Fs30 Hz −13%

Qts0.37 +16%

Vas32.4 L −26%

BL8.2 T·m –

Xmax5.5 mm −31%

Sensitivity85.4 dB −3.2

Scanspeak18W/8545K00

£144.00

Fs28 Hz −18%

Qts0.28 −12%

Vas46.4 L +5%

BL8.2 T·m –

Xmax6.5 mm −19%

Sensitivity87.3 dB −1.3

SB AcousticsMW16P-8

£145.30

Fs29 Hz −15%

Qts0.33 +3%

Vas48 L +9%

BL6.3 T·m −21%

Xmax12 mm +50%

Sensitivity87.3 dB −1.3

SB AcousticsMW16PNW-8

£148.17

Fs29 Hz −15%

Qts0.32 –

Vas49.9 L +13%

BL6.3 T·m −21%

Xmax12 mm +50%

Sensitivity87.6 dB −1

SB AcousticsMW16P-12

£148.17

Fs31 Hz −10%

Qts0.37 +16%

Vas47.3 L +7%

BL7.4 T·m −7%

Xmax12.4 mm +55%

Sensitivity87.3 dB −1.3

SB AcousticsMR16PNW-8

£160.88

Fs31 Hz −9%

Qts0.32 –

Vas44.8 L –

BL6.5 T·m −19%

Xmax6.2 mm −22%

Sensitivity88 dB −0.6

SB AcousticsMR16P-8

£160.88

Fs32 Hz −6%

Qts0.30 −6%

Vas44.3 L –

BL6.5 T·m −19%

Xmax6.2 mm −22%

Sensitivity88.6 dB –

Scanspeak18W/4531G01

£168.82

Fs34 Hz –

Qts0.35 +9%

Vas45.6 L +4%

BL5.7 T·m −29%

Xmax6.5 mm −19%

Sensitivity88.8 dB –

Scanspeak18W/4531G00

£182.05

Fs33 Hz –

Qts0.35 +9%

Vas41.9 L −5%

BL5.7 T·m −29%

Xmax6.5 mm −19%

Sensitivity88 dB −0.6

WavecorWF182BD20

£190.56

Fs30 Hz −13%

Qts0.37 +16%

Vas32.4 L −26%

BL8.2 T·m –

Xmax5.5 mm −31%

Sensitivity85.4 dB −3.2

SB AcousticsMW16TX-8

£253.24

Fs29 Hz −14%

Qts0.33 +3%

Vas48 L +9%

BL6.3 T·m −21%

Xmax12 mm +50%

Sensitivity87.4 dB −1.2

SEASE0042-08S W18NX001

£254.04

Fs40 Hz +18%

Qts0.34 +6%

Vas24 L −45%

BL7 T·m −13%

Xmax7 mm −13%

Sensitivity87.8 dB −0.8

SB AcousticsMW19TX-8

£287.12

Fs33 Hz –

Qts0.33 +3%

Vas53.4 L +21%

BL7.5 T·m −6%

Xmax13.4 mm +68%

Sensitivity89.4 dB +0.8

Scanspeak18WU/8747T00

£287.92

Fs36 Hz +6%

Qts0.38 +19%

Vas36.2 L −18%

BL7.4 T·m −7%

Xmax9 mm +13%

Sensitivity88 dB −0.6

Scanspeak18WU/4747T00

£292.16

Fs36 Hz +6%

Qts0.35 +9%

Vas36 L −18%

BL5.9 T·m −26%

Xmax9 mm +13%

Sensitivity88.4 dB –

Scanspeak18WU/4741T00

£313.33

Fs34 Hz –

Qts0.36 +12%

Vas38.4 L −13%

BL5.9 T·m −26%

Xmax9 mm +13%

Sensitivity87.9 dB −0.7

SEASE0073-08 W16NX003

£423.44

Fs36 Hz +6%

Qts0.34 +6%

Vas17 L −61%

BL7.6 T·m −5%

Xmax7 mm −13%

Sensitivity85.5 dB −3.1

SEASE0117-08 W19NX004

£508.13

Fs33 Hz –

Qts0.39 +22%

Vas33 L −25%

BL7.9 T·m –

Xmax7 mm −13%

Sensitivity86.5 dB −2.1

AccutonAS168-9-470

£685.19

Fs27 Hz −21%

Qts0.35 +9%

Vas35.5 L −19%

BL12.1 T·m +51%

Xmax8 mm –

Sensitivity84.7 dB −3.9

Scanspeak18WE/8542T00

£846.91

Fs50 Hz +47%

Qts0.32 –

Vas16 L −64%

BL9.7 T·m +21%

Xmax7.7 mm −4%

Sensitivity89.7 dB +1.1

SEASE0096-08 W18NX003

No current price

Fs35 Hz –

Qts0.34 +6%

Vas31 L −30%

BL7.4 T·m −7%

Xmax7 mm −13%

Sensitivity87.5 dB −1.1

Audio Technology6 H 52 17 06 SD

No current price

Fs33 Hz –

Qts0.35 +9%

Vas47 L +7%

BL6.6 T·m −18%

Xmax6.3 mm −21%

Sensitivity88.1 dB −0.5

SEASH1869-08 L16RNX/T

No current price

Fs32 Hz −6%

Qts0.33 +3%

Vas18 L −59%

BL8.7 T·m +9%

Xmax7 mm −13%

Sensitivity84.3 dB −4.3

PurifiPTT6.5X08-NFA-06

No current price

Fs31 Hz −9%

Qts0.34 +6%

Vas26 L −41%

BL8.9 T·m +11%

Xmax9.8 mm +23%

Sensitivity85.4 dB −3.2
