Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespVisaton BG 20 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverBG series
Visaton
Visaton BG 20
Visaton BG 20 is a 8" 8 ohm LF driver rated at 40W RMS. The validated T/S data includes Fs 38Hz, Qts 0.44, Vas 110L, Xmax 6mm, sensitivity 92.8dB, plus 128cm³ Vd and 75 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £30.00.
Size
8"
Impedance
8Ω
RMS Power
40W
Sensitivity
92.8dB
EBP
75
Either alignment
Vd
128cm³
T/S Parameters
Valid
Fs38Hz
Qts0.44
Qes0.51
Qms3.5
Vas110.0L
Re6.2Ω
Le0.80mH
BL6.1Tm
Sd214cm²
Mms10g
Xmax6.0mm
SPL93dB
Power40W
Impedance8Ω
F High18000Hz
Voice Coil25mm
Flux Density1.20T
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorsoundimports
Updated 11 Sept 2026
Source: inc VAT
£37.76
inc VAT
Out of stock
Best current price
Updated 11 Sept 2026
thomann
£30.00
inc VAT·In stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.3kg
Diameter200.0mm
Cutout Diameter184.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Visaton
BG 20
8"
Best current price
£30.00
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
76%
Similarity
122% more£66.55
Dayton Audio
RS225-4
8"
Higher price
Xmax6mm0%
Qts0.41-7%
BL6.4Tm+5%
Vas46.4L-58%
Qes0.52+2%
70%
Similarity
122% more£66.55
Dayton Audio
RS225P-4A
8"
Higher price
Xmax6mm0%
Qts0.38-14%
BL6.4Tm+5%
Vas45.8L-58%
Qes0.48-6%
83%
Similarity
179% more£83.70
CIARE
HW202
8"
Higher price
Xmax6.5mm+8%
Qts0.440%
BL6.7Tm+10%
Vas83L-25%
Qes0.52+2%
66%
Similarity
186% more£85.75
Scanspeak
22W/8534G00
8"
Higher price
Xmax5.8mm-3%
Qts0.39-11%
BL7.8Tm+28%
Vas94.2L-14%
Qes0.43-16%
66%
Similarity
280% more£113.95
Scanspeak
22W/4534G00
8"
Higher price
Xmax5.7mm-5%
Qts0.34-23%
BL6Tm-2%
Vas95L-14%
Qes0.37-27%
49%
Similarity
384% more£145.25
Scanspeak
18W/8535-01
7"
Higher price
Xmax5mm-17%
Qts0.38-14%
BL5.9Tm-3%
Vas68.9L-37%
Qes0.46-10%
38%
Similarity
463% more£168.81
Scanspeak
18W/8531G00
7"
Higher price
Xmax6.5mm+8%
Qts0.36-18%
BL6.8Tm+11%
Vas58.2L-47%
Qes0.39-24%
35%
Similarity
463% more£168.82
Scanspeak
18W/4531G01
7"
Higher price
Xmax6.5mm+8%
Qts0.35-20%
BL5.7Tm-7%
Vas45.6L-59%
Qes0.38-25%
100%
Similarity
Visaton
BG 20 - 8 OHM
8"
Xmax6mm0%
Qts0.440%
BL6.1Tm0%
Vas110L0%
Qes0.510%
82%
Similarity
HiVi
S8-98
8"
Xmax5.8mm-3%
Qts0.440%
BL6.6Tm+8%
Vas64.9L-41%
Qes0.52+2%
79%
Similarity
Tang Band
W8-2314
8"
Xmax6mm0%
Qts0.46+5%
BL6.1Tm0%
Vas49.5L-55%
Qes0.54+6%
76%
Similarity
HiVi
S8-98R
8"
Xmax6mm0%
Qts0.42-5%
BL6.9Tm+13%
Vas65.2L-41%
Qes0.47-8%
