REDCATT 4FR-2 4Ω
4 Ω
£16.95
Lautsprecherteile · 12 in stock · All 1 offer
- Fs
- 80Hz
- Xmax
- 0.35mm
- SPL
- 84dB
- Pe
- 30W
- BL
- 4.6T·m
- Vd
- 2cm³
- Qts
- 0.51
- Vas
- 2L
REDCATT 4FR-2 is a 4-inch 4 ohm LF driver rated at 30 W RMS. The validated T/S data includes Fs 80 Hz, Qts 0.51, Vas 2.0 L, Xmax 0.35 mm, sensitivity 84.4 dB, plus 2 cm³ Vd and 138 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £16.95.
The published T/S values agree with each other
Thiele/Small
- Fs
- 80Hz
- Qts
- 0.51
- Qes
- 0.58
- Qms
- 4.2
- Vas
- 2.0L
- Re
- 3.3Ω
- Le
- 0.29mH
Motor and cone
- BL
- 4.6T·m
- Sd
- 50cm²
- Mms
- 7g
- Xmax
- 0.35mm
- Vd †
- 2cm³
- Voice coil
- 25mm
Power and response
- Sensitivity †
- 84.4dB
- Manufacturer sensitivity
- 85.1dB
- Power
- 30W
- Impedance
- 4Ω
- EBP †
- 138 · Leans vented
Size and mounting
- Diameter
- 116mm
- Cutout
- 94.5mm
- Bolt circle
- 109mm
- Weight
- 0.8kg
Other published values
- Xmech
- 4.65
- Power Peak
- 120
Other dimensions
- Mounting Depth
- 55.9
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 4″
- BL
- 4.6T·m
- Fs
- 80Hz
- Le
- 0.29mH
- Re
- 3.3Ω
- Sd
- 50cm²
- Mms
- 7g
- Qes
- 0.58
- Qms
- 4.2
- Qts
- 0.51
- SPL
- 84.4dB
- Vas
- 2.0L
- Xmax
- 0.35mm
- Xmech
- 4.65
- Power
- 30W
- Impedance
- 4Ω
- Power Peak
- 120
- Sensitivity
- 85.1dB
- Calculated sensitivity †
- 84.4dB
- Manufacturer sensitivity
- 85.1dB
- Voice coil
- 25mm
- Weight
- 0.8kg
- Diameter
- 116mm
- Mounting Depth
- 55.9
- Cutout
- 94.5mm
- Bolt circle
- 109mm
