T/S Parameters
Valid
Fs32Hz
Qts0.32
Qes0.33
Qms12.0
Vas33.6L
Re5.1Ω
Le0.10mH
BL10.2Tm
Sd179cm²
Mms34g
Xmax12.0mm
Impedance8Ω
F Low35Hz
F High2000Hz
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Diameter185.0mm
Similar Drivers
Keep size fixed, then add or remove T/S params to change the ranking and the comparison rows.
Reference
Kartesian
Wom185_vKi
7.25"
