Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Not enough T/S data
Missing Le, RMS power
Media
Wavecor
WF152BD13
Image unavailable
Overview
LF DriverWF152BD series
Wavecor
Wavecor WF152BD13
Wavecor WF152BD13 is a 6" 4 ohm LF driver. The validated T/S data includes Fs 50Hz, Qts 0.33, Vas 9.2L, Xmax 4.5mm, sensitivity 87.3dB, plus 42cm³ Vd and 147 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £98.11.
Size
6"
Impedance
4Ω
Sensitivity
87.3dB
EBP
147
Vented alignment
Vd
42cm³
T/S Parameters
Valid
Fs50Hz
Qts0.33
Qes0.34
Qms10.3
Vas9.2L
Re3.2Ω
BL6.3Tm
Sd93cm²
Mms14g
Xmax4.5mm
SPL87dB
Impedance4Ω
Voice Coil32mm
Pricing & availability
Price definitionsPrice movement
Best current price
£98.11
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Not enough T/S data
Missing Le, RMS power
BASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Not enough T/S data
Missing Le, RMS power
VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Not enough T/S data
Missing Le, RMS power
00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter152.4mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Image unavailable
Reference
Wavecor
WF152BD13
6"
Best current price
£98.11
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
48%
Similarity
72% cheaper£27.70
Dayton Audio
DSA135-8
5"
Lower price
Xmax4.9mm+9%
Qts0.38+15%
BL6.2Tm-2%
Vas7.9L-14%
Qes0.47+38%
29%
Similarity
59% cheaper£40.47
CIARE
CME160
6.5"
Lower price
Xmax3.5mm-22%
Qts0.4+21%
BL7.6Tm+20%
Vas4.5L-51%
Qes0.45+32%
26%
Similarity
50% cheaper£48.95
Monacor
SPH-5M
5"
Lower price
Xmax3.5mm-22%
Qts0.41+24%
BL6.4Tm+1%
Vas13.5L+47%
Qes0.47+38%
41%
Similarity
36% cheaper£63.23
Beyma
5P200FE
5"
Lower price
Xmax5.7mm+27%
Qts0.330%
BL8.5Tm+34%
Vas5.7L-38%
Qes0.35+3%
53%
Similarity
32% cheaper£66.95
Scanspeak
15W/8434G00
6"
Lower price
Xmax4.2mm-7%
Qts0.25-24%
BL7.3Tm+15%
Vas12.8L+39%
Qes0.27-21%
Image unavailable
91%
Similarity
12% more£110.10
Wavecor
WF152BD09
6"
Higher price
Xmax4.5mm0%
Qts0.34+3%
BL5.8Tm-9%
Vas8.6L-7%
Qes0.35+3%
41%
Similarity
14% more£111.62
CIARE
CMI160ND
6.5"
Higher price
Xmax4.5mm0%
Qts0.41+24%
BL7.8Tm+23%
Vas6L-35%
Qes0.45+32%
22%
Similarity
29% more£126.11
Beyma
5CX200FE
5"
Higher price
Xmax5.7mm+27%
Qts0.41+24%
BL7.4Tm+17%
Vas5.3L-42%
Qes0.43+26%
46%
Similarity
196% more£289.95
Scanspeak
12MU/8731T00
5"
Higher price
Xmax3.4mm-24%
Qts0.29-12%
BL6.1Tm-4%
Vas5.8L-37%
Qes0.31-9%
Image unavailable
100%
Similarity
Wavecor
WF152BD05
6"
Xmax4.5mm0%
Qts0.330%
BL6.3Tm0%
Vas9.2L0%
Qes0.340%
Image unavailable
91%
Similarity
Wavecor
WF152BD10
6"
Xmax4.5mm0%
Qts0.32-3%
BL5.8Tm-9%
Vas9.6L+4%
Qes0.33-3%
Image unavailable
80%
Similarity
Wavecor
WF152BD06
6"
Xmax4.5mm0%
Qts0.29-12%
BL6.3Tm0%
Vas11.5L+25%
Qes0.3-12%
