6-inch LF driver · WF152BD series · 32 mm voice coil

Wavecor WF152BD05 4Ω

Name: Wavecor WF152BD05 4 Ohm
Brand: Wavecor
SKU: WF152BD05

4 Ω

No current price

View offers

Open in 00 Simulator

Fs: 50Hz
Xmax: 4.5mm
SPL: 87dB
Pe: –
BL: 6.3T·m
Vd: 42cm³
Qts: 0.33
Vas: 9L

See all 18 specs

Specifications

Published by Wavecor

Manufacturer page

Datasheet PDF

Wavecor WF152BD05 is a 6-inch 4 ohm LF driver. The validated T/S data includes Fs 50 Hz, Qts 0.33, Vas 9.2 L, Xmax 4.5 mm, sensitivity 87.3 dB, plus 42 cm³ Vd and 147 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 50Hz
Qts: 0.33
Qes: 0.34
Qms: 10.3
Vas: 9.2L
Re: 3.2Ω

Motor and cone

BL: 6.3T·m
Sd: 93cm²
Mms: 14g
Xmax: 4.5mm
Vd †: 42cm³
Voice coil: 32mm

Power and response

Sensitivity †: 87.3dB
Impedance: 4Ω
EBP †: 147 · Leans vented

Size and mounting

Diameter: 152.4mm

Other published values

Cms: 0.75mm/N
Rms: 0.41kg/s

† Calculated by bits from the published values

What this validation status means

Everything else Wavecor lists

LF · Primary · 6″

BL: 6.3T·m
Fs: 50Hz
Re: 3.2Ω
Sd: 93cm²
Cms: 0.75mm/N
Mms: 14g
Qes: 0.34
Qms: 10.3
Qts: 0.33
Rms: 0.41kg/s
SPL: 87.3dB
Vas: 9.2L
Xmax: 4.5mm
Impedance: 4Ω
Calculated sensitivity †: 87.3dB
Voice coil: 32mm
Diameter: 152.4mm

Compare

Same-size drivers, compared with the WF152BD05. Clear differences are green when better and red when worse.

This driverWF152BD05

Best price

–

50 Hz

Qts

0.33

Vas

9.2 L

6.3 T·m

Xmax

4.5 mm

Sensitivity

87.3 dB

Power

–

FaitalPRO5FE100

£21.36

Fs65 Hz +30%

Qts0.33 –

Vas6.1 L −34%

BL6 T·m −6%

Xmax5.2 mm +16%

Sensitivity88.8 dB +1.5

SB AcousticsSB13PFC25-8

£22.98

Fs45 Hz −10%

Qts0.33 –

Vas13.4 L +46%

BL6.2 T·m –

Xmax4.5 mm –

Sensitivity87 dB –

SB AcousticsSB13PFCR25-8

£22.98

Fs45 Hz −10%

Qts0.33 –

Vas13.4 L +46%

BL6.2 T·m –

Xmax4.5 mm –

Sensitivity87 dB –

SB AcousticsSB13PFC25-4

£22.98

Fs44 Hz −12%

Qts0.29 −12%

Vas13.4 L +46%

BL5.3 T·m −17%

Xmax4.5 mm –

Sensitivity87.4 dB –

SB AcousticsSB13PFCR25-4

£22.98

Fs44 Hz −12%

Qts0.29 −12%

Vas13.4 L +46%

BL5.3 T·m −17%

Xmax4.5 mm –

Sensitivity87.4 dB –

SB AcousticsSB15NRXC30-8

£54.13

Fs38 Hz −24%

Qts0.33 –

Vas20.7 L +125%

BL5.6 T·m −12%

Xmax5 mm +11%

Sensitivity87.1 dB –

Scanspeak12W/8524G00

£54.43

Fs52 Hz +4%

Qts0.32 −3%

Vas8.2 L −11%

BL5.4 T·m −15%

Xmax3 mm −33%

Sensitivity87.2 dB –

Sica5 NR 1.5 PL

£63.80

Fs61 Hz +22%

Qts0.35 +6%

Vas7.4 L −20%

BL6.7 T·m +5%

Xmax3.5 mm −22%

Sensitivity88.4 dB +1.1

CIAREHWB160

£66.98

Fs46 Hz −8%

Qts0.36 +9%

Vas19.5 L +112%

BL6.5 T·m –

Xmax4.5 mm –

Sensitivity89 dB +1.7

SB AudienceROSSO-6MW150D

£67.15

Fs66 Hz +32%

Qts0.32 −3%

Vas8.8 L −4%

BL11.6 T·m +83%

Xmax5.2 mm +16%

Sensitivity90.9 dB +3.6

Scanspeak18W/4434G00

£72.01

Fs47 Hz −6%

Qts0.35 +6%

Vas20.7 L +125%

BL6 T·m −6%

Xmax4.3 mm −4%

Sensitivity89.7 dB +2.4

ETON5-512/C8/25 RP

£83.69

Fs59 Hz +18%

Qts0.34 +3%

Vas10 L +9%

BL5.9 T·m −7%

Xmax2.5 mm −44%

Sensitivity89.7 dB +2.4

B&C6PS44

£86.62

Fs71 Hz +42%

Qts0.33 –

Vas7 L −24%

BL11 T·m +73%

Xmax4.5 mm –

Sensitivity90.7 dB +3.4

Dayton AudioPS180-8

£89.75

Fs59 Hz +17%

Qts0.33 –

Vas27.6 L +200%

BL6.8 T·m +7%

Xmax4.6 mm –

Sensitivity93.9 dB +6.6

WavecorWF152BD13

£98.00

Fs50 Hz –

Qts0.33 –

Vas9.2 L –

BL6.3 T·m –

Xmax4.5 mm –

Sensitivity87.3 dB –

SEASH1520-08 U16RCY/P

£101.03

Fs36 Hz −28%

Qts0.32 −3%

Vas25 L +172%

BL6.3 T·m –

Xmax4 mm −11%

Sensitivity86.9 dB –

WavecorWF152BD09

£109.96

Fs52 Hz +4%

Qts0.34 +3%

Vas8.6 L −7%

BL5.8 T·m −9%

Xmax4.5 mm –

Sensitivity87.4 dB –

WavecorWF152BD03

£142.76

Fs56 Hz +11%

Qts0.35 +6%

Vas9.2 L –

BL5.8 T·m −9%

Xmax4.5 mm –

Sensitivity88.4 dB +1.1

WavecorWF152BD04

£142.76

Fs50 Hz –

Qts0.31 −6%

Vas11.4 L +24%

BL7.3 T·m +15%

Xmax4.5 mm –

Sensitivity88.4 dB +1.1

WavecorWF152BD12

£149.88

Fs46 Hz −8%

Qts0.38 +15%

Vas9.6 L +4%

BL7.2 T·m +13%

Xmax4.5 mm –

Sensitivity85.7 dB −1.6

SB AcousticsMW13TX-8

£225.24

Fs40 Hz −20%

Qts0.32 −3%

Vas14.8 L +61%

BL5.7 T·m −10%

Xmax5 mm +11%

Sensitivity86.5 dB −0.8

WavecorWF152BD10

No current price

Fs49 Hz –

Qts0.32 −3%

Vas9.6 L +4%

BL5.8 T·m −9%

Xmax4.5 mm –

Sensitivity87.4 dB –

WavecorWF152BD06

No current price

Fs45 Hz −11%

Qts0.29 −12%

Vas11.5 L +25%

BL6.3 T·m –

Xmax4.5 mm –

Sensitivity87.3 dB –

WavecorWF152BD14

No current price

Fs45 Hz −11%

Qts0.29 −12%

Vas11.5 L +25%

BL6.3 T·m –

Xmax4.5 mm –

Sensitivity87.3 dB –

Sica6 NR 2 PL

No current price

Fs61 Hz +21%

Qts0.33 –

Vas9.4 L –

BL9.9 T·m +55%

Xmax4 mm −11%

Sensitivity89.9 dB +2.6

Sica5.5 H 1.5 CP

No current price

Fs48 Hz −4%

Qts0.37 +12%

Vas8.4 L −9%

BL7.2 T·m +14%

Xmax4.5 mm –

Sensitivity85.7 dB −1.6

KartesianWOM145_VMS

No current price

Fs48 Hz −4%

Qts0.36 +8%

Vas9.9 L +7%

BL6.6 T·m +4%

Xmax4.5 mm –

Sensitivity87 dB –

WavecorWF152BD08

No current price

Fs46 Hz −8%

Qts0.35 +6%

Vas11.5 L +25%

BL8 T·m +26%

Xmax4.5 mm –

Sensitivity87 dB –

WavecorWF152BD16

No current price

Fs46 Hz −8%

Qts0.35 +6%

Vas11.5 L +25%

BL8 T·m +26%

Xmax4.5 mm –

Sensitivity87 dB –

Beyma6CX200FE

No current price

Fs65 Hz +30%

Qts0.32 −3%

Vas10.5 L +15%

BL9.2 T·m +45%

Xmax5 mm +11%

Sensitivity91.3 dB +4

Search similar

Tune the match

Choose the published values that matter to your design. Size stays matched to this driver.

Qts

Qes

Vas

Xmax

Where to buy

Prices for delivery to the UK, including VAT. How prices work

Watch price

No current price found. Pricing may appear after the next vendor refresh.
