Overview
LF Driver
Sica
Sica 5.5 H 1.5 CP
Sica 5.5 H 1.5 CP is a 5.5" 8 ohm LF driver rated at 120W RMS. The validated T/S data includes Fs 48Hz, Qts 0.37, Vas 8.4L, Xmax 4.5mm, sensitivity 85.7dB, plus 35cm³ Vd and 120 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
5.5"
Impedance
8Ω
RMS Power
120W
Sensitivity
85.7dB
86.7dBmanufacturer; using T/S-derived value (1.0dB delta).
EBP
120
Vented alignment
Vd
35cm³
T/S Parameters
Valid
Fs48Hz
Qts0.37
Qes0.40
Qms4.1
Vas8.4L
Re6.1Ω
Le0.53mH
BL7.2Tm
Sd79cm²
Mms11g
Xmax4.5mm
SPL86dB
Power120W
Impedance8Ω
Voice Coil38mm
Flux Density0.98T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.5kg
Diameter148.0mm
Overall Depth71.5mm
Cutout Diameter113.0mm
Bolt Circle Diameter139.0mm
