Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Not enough T/S data
Missing RMS power
Sica 6.5 C 1.5 CP 8Ω
LF DriverMedia
Auto-advancing
Overview
LF Driver
Sica
Sica 6.5 C 1.5 CP
Sica 6.5 C 1.5 CP is a 6.5" 8 ohm LF driver. The validated T/S data includes Fs 51Hz, Qts 0.39, Vas 15.9L, Xmax 4.5mm, sensitivity 89dB, plus 55cm³ Vd and 121 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
8Ω
Sensitivity
89.0dB
91.0dBmanufacturer; using T/S-derived value (2.0dB delta).
EBP
121
Vented alignment
Vd
55cm³
Overall Parameters
Valid
Fs51Hz
Qts0.39
Qes0.42
Qms6.1
Vas15.9L
Re5.1Ω
Le0.44mH
BL7.2Tm
Sd123cm²
Mms13g
Xmax4.5mm
SPL89dB
Impedance8Ω
Voice Coil38mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
What this validation status meansPricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Not enough T/S data
Missing RMS power
BASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Not enough T/S data
Missing RMS power
VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Not enough T/S data
Missing RMS power
00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.7kg
Diameter175.0mm
Overall Depth79.5mm
Cutout Diameter143.0mm
Bolt Circle Diameter164.2mm
Driver Components
LFLF
6.5"Fs51 Hz
Qts0.39
Qes0.42
Qms6.1
Vas15.9 L
Re5.1 Ω
Le0.44 mH
BL7.2 Tm
Sd123 cm²
Mms13 g
Xmax4.5 mm
SPL89 dB
Impedance8 Ω
Voice Coil38 mm
Cms0.745
HFHF
Fs1500 Hz
Re6.0 Ω
SPL94 dB
Impedance8 Ω
Xover3000 Hz
Voice Coil25 mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Sica
6.5 C 1.5 CP
6.5"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
81%
Similarity
HiVi
D6.4+
6.5"
Xmax4mm-11%
Qts0.36-8%
BL6.6Tm-9%
Vas13.9L-13%
Qes0.420%
80%
Similarity
CIARE
HWB160
6.5"
Xmax4.5mm0%
Qts0.36-8%
BL6.5Tm-10%
Vas19.5L+23%
Qes0.38-10%
79%
Similarity
CIARE
CMI160
6.5"
Xmax4.5mm0%
Qts0.41+5%
BL7.2Tm0%
Vas7.8L-51%
Qes0.45+7%
78%
Similarity
CIARE
HW161N
6.5"
Xmax5mm+11%
Qts0.37-5%
BL7.4Tm+3%
Vas19.9L+25%
Qes0.46+10%
77%
Similarity
CIARE
CW161N
6.5"
Xmax4mm-11%
Qts0.35-10%
BL6.1Tm-16%
Vas17.4L+9%
Qes0.420%
Image unavailable
77%
Similarity
Wavecor
WF152BD11
6"
Xmax4.5mm0%
Qts0.4+3%
BL7.2Tm0%
Vas8.6L-46%
Qes0.420%
77%
Similarity
HiVi
E6.5N
6.5"
Xmax4.3mm-6%
Qts0.4+3%
BL7.1Tm-1%
Vas21L+32%
Qes0.51+21%
Image unavailable
77%
Similarity
Wavecor
WF152BD12
6"
Xmax4.5mm0%
Qts0.38-3%
BL7.2Tm0%
Vas9.6L-40%
Qes0.4-5%
77%
Similarity
Tang Band
W6-2313
6"
Xmax4mm-11%
Qts0.4+3%
BL7.1Tm-2%
Vas13.3L-16%
Qes0.44+5%
76%
Similarity
HiVi
F6N
6"
Xmax4.5mm0%
Qts0.43+10%
BL7.3Tm+1%
Vas19.1L+20%
Qes0.45+7%
76%
Similarity
CIARE
HW172
7"
Xmax4.5mm0%
Qts0.37-5%
BL7.6Tm+5%
Vas20L+26%
Qes0.45+7%
75%
Similarity
£765.75
Accuton
C168-6-890
6.5"
Xmax5mm+11%
Qts0.44+13%
BL7.5Tm+4%
Vas15L-6%
Qes0.49+17%
