CIARE HWB160
CIARE HWB160 is a 6.5" 8 ohm LF driver rated at 80W RMS. The validated T/S data includes Fs 43Hz, Qts 0.37, Vas 28L, Xmax 4.5mm, sensitivity 89.4dB, plus 63cm³ Vd and 105 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
8Ω
RMS Power
80W
Sensitivity
89.4dB
91.0dBmanufacturer; using T/S-derived value (1.6dB delta).
EBP
105
Vented alignment
Vd
63cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
frequency response240 ptsp1medium
Curve provenanceInspect 2 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
frequency response
Frequency response
240 plotted pointsMedium confidence2,231 selected pixels of 2,231 - Trace datasheet-response-trace-poc/v1
free air impedance
Impedance response
240 plotted pointsMedium confidence2,160 selected pixels of 2,160
T/S Parameters
Valid
Fs43Hz
Qts0.37
Qes0.41
Qms4.7
Vas28.0L
Re5.8Ω
Le1.30mH
BL7.3Tm
Sd141cm²
Mms14g
Xmax4.5mm
SPL89dB
Power80W
Power Nominal80W
Impedance8Ω
F Low45Hz
F High5000Hz
Voice Coil32mm
Pricing & availability
Price definitionsVendor offers
1 vendorleanaudio
Updated 11 Sept 2026· 8Ω
Source: inc VAT · 20%
£58.32
inc VAT
Back order
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.6kg
Diameter174.0mm
Overall Depth79.0mm
Cutout Diameter146.0mm
Bolt Circle Diameter164.0mm
