Overview
LF DriverSC series
Visaton
Visaton SC 5.9 ND
Visaton SC 5.9 ND is a 2" 8 ohm LF driver rated at 3W RMS. The validated T/S data includes Fs 280Hz, Qts 4.11, Vas 0.4L, Xmax 1mm, sensitivity 81.5dB, plus 3cm³ Vd and 28 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £9.16.
Size
2"
Impedance
8Ω
RMS Power
3W
Sensitivity
81.5dB
EBP
28
Sealed alignment
Vd
3cm³
T/S Parameters
Valid
Fs280Hz
Qts4.11
Qes10.02
Qms7.0
Vas0.4L
Re7.7Ω
Le0.40mH
BL1.2Tm
Sd27cm²
Mms1g
Xmax1.0mm
SPL82dB
Power3W
Impedance8Ω
F Low150Hz
F High17000Hz
Voice Coil14mm
Flux Density0.75T
Pricing & availability
Price definitionsPrice movement
Best current price
Updated 11 Sept 2026
partsexpress
£9.16
inc VAT·43 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight60.0kg
Diameter90.0mm
Cutout Diameter43.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Visaton
SC 5.9 ND
2"
Best current price
£9.16
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
2 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
100%
Similarity
Visaton
SC 5.9 ND - 8 OHM
2"
Xmax1mm0%
Qts4.110%
BL1.2Tm0%
Vas0.4L0%
Qes10.020%
72%
Similarity
Visaton
SC 5.9 ND - 4 OHM
2"
Xmax1mm0%
Qts4.3+5%
BL1Tm-17%
Vas0.3L-25%
Qes8.03-20%
