Overview
LF DriverCF series
Monacor
Monacor CF0617M/8
Monacor CF0617M/8 is a 6.5" 8 ohm LF driver rated at 200W RMS. The validated T/S data includes Fs 117Hz, Qts 0.45, Vas 5.4L, Xmax 2.7mm, sensitivity 94.5dB, plus 42cm³ Vd and 242 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
8Ω
RMS Power
200W
Sensitivity
94.5dB
96.0dBmanufacturer; using T/S-derived value (1.5dB delta).
EBP
242
Vented alignment
Vd
42cm³
T/S Parameters
Valid
Fs117Hz
Qts0.45
Qes0.48
Qms6.9
Vas5.4L
Re5.3Ω
Le1.73mH
BL9.0Tm
Sd154cm²
Mms12g
Xmax2.7mm
SPL95dB
Power200W
Impedance8Ω
F Low300Hz
F High7000Hz
Voice Coil45mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.9kg
Diameter189.0mm
Overall Depth78.5mm
Cutout Diameter150.0mm
