Overview
LF DriverALPHA series
Eminence
Eminence ALPHA 6C
Eminence ALPHA 6C is a 6" 4 ohm LF driver rated at 100W RMS. The validated T/S data includes Fs 107Hz, Qts 0.45, Vas 5.7L, Xmax 3.5mm, sensitivity 93.6dB, plus 44cm³ Vd and 218 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £54.73.
Size
6"
Impedance
4Ω
RMS Power
100W
Sensitivity
93.6dB
EBP
218
Vented alignment
Vd
44cm³
T/S Parameters
Valid
Fs107Hz
Qts0.45
Qes0.49
Qms6.1
Vas5.7L
Re3.2Ω
Le0.28mH
BL6.4Tm
Sd127cm²
Mms9g
Xmax3.5mm
SPL94dB
Power100W
Impedance4Ω
F Low95Hz
F High5000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£54.73
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.9kg
Diameter167.4mm
Overall Depth71.1mm
Cutout Diameter143.5mm
Bolt Circle Diameter153.9mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
ALPHA 6C
6"
Best current price
£54.73
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
58%
Similarity
41% cheaper£32.19
Dayton Audio
SIG150-4
6"
Lower price
Xmax4mm+14%
Qts0.49+9%
BL5.2Tm-19%
Vas8.7L+53%
Qes0.53+8%
65%
Similarity
40% cheaper£32.65
Celestion
TRUVOX 0615
6.5"
Lower price
Xmax3.5mm0%
Qts0.47+5%
BL8Tm+25%
Vas7.4L+31%
Qes0.52+5%
52%
Similarity
38% cheaper£33.69
Dayton Audio
RS125P-8
5"
Lower price
Xmax4mm+14%
Qts0.44-2%
BL5.1Tm-21%
Vas4L-30%
Qes0.53+8%
66%
Similarity
26% cheaper£40.47
CIARE
CME160
6.5"
Lower price
Xmax3.5mm0%
Qts0.4-11%
BL7.6Tm+19%
Vas4.5L-21%
Qes0.45-8%
66%
Similarity
6% cheaper£51.68
Celestion
TFX0515
5"
Lower price
Xmax3.8mm+7%
Qts0.47+5%
BL7Tm+9%
Vas6.5L+15%
Qes0.5+3%
65%
Similarity
8% more£59.00
Eminence
ALPHA-6A
6"
Higher price
Xmax3.5mm0%
Qts0.54+20%
BL8Tm+25%
Vas5.8L+2%
Qes0.6+22%
51%
Similarity
15% more£62.80
FaitalPRO
6PR110
6"
Higher price
Xmax2.8mm-21%
Qts0.53+18%
BL8.5Tm+33%
Vas5.6L-2%
Qes0.6+22%
29%
Similarity
17% more£64.09
Eminence
BETA-6A
6"
Higher price
Xmax4.5mm+29%
Qts0.56+24%
BL8.1Tm+27%
Vas3.5L-38%
Qes0.66+35%
39%
Similarity
58% more£86.62
B&C
6PEV13
6.5"
Higher price
Xmax2.5mm-29%
Qts0.36-20%
BL8.2Tm+28%
Vas6L+5%
Qes0.39-20%
Image unavailable
36%
Similarity
101% more£110.10
Wavecor
WF152BD09
6"
Higher price
Xmax4.5mm+29%
Qts0.34-24%
BL5.8Tm-9%
Vas8.6L+51%
Qes0.35-29%
54%
Similarity
104% more£111.62
CIARE
CMI160ND
6.5"
Higher price
Xmax4.5mm+29%
Qts0.41-9%
BL7.8Tm+22%
Vas6L+5%
Qes0.45-8%
76%
Similarity
Celestion
TFX0512
5"
Xmax3.3mm-7%
Qts0.46+2%
BL6.4Tm0%
Vas5.4L-6%
Qes0.49+1%
