Overview
LF DriverTFX0515 series
Celestion
Celestion TFX0515
Celestion TFX0515 is a 5" 8 ohm LF driver rated at 10W RMS. The validated T/S data includes Fs 74Hz, Qts 0.47, Vas 6.5L, Xmax 3.8mm, sensitivity 89.2dB, plus 36cm³ Vd and 147 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £52.50.
Size
5"
Impedance
8Ω
RMS Power
10W
Sensitivity
89.2dB
96.0dBmanufacturer; using T/S-derived value (6.8dB delta).
EBP
147
Vented alignment
Vd
36cm³
T/S Parameters
Valid
Fs74Hz
Qts0.47
Qes0.50
Qms8.3
Vas6.5L
Re5.8Ω
Le0.36mH
BL7.0Tm
Sd95cm²
Mms9g
Xmax3.8mm
SPL89dB
Power10W
Impedance8Ω
Voice Coil25mm
Pricing & availability
Price definitionsPrice movement
Other offers
2 vendorsleanbusiness
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£55.00
inc VAT
partsexpress
Updated 11 Sept 2026
Source: ex VAT
£58.43
inc VAT
15 in stock
Best current price
Updated 11 Sept 2026
leanaudio
£52.50
Avg £55.31£2.81 below avg (-5.1%)
inc VAT·2 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.6kg
Diameter151.0mm
Overall Depth72.0mm
Cutout Diameter116.0mm
Bolt Circle Diameter140.0mm
