12-inch LF driver · LBASS12 series · 38 mm voice coil · 100 W
Lavoce LBASS12-15 8Ω
8 Ω · 40–4000 Hz
No current price
- Fs
- 38Hz
- Xmax
- 4.7mm
- SPL
- 94dB
- Pe
- 100W
- BL
- 10.1T·m
- Vd
- 251cm³
- Qts
- 0.48
- Vas
- 161L
Lavoce LBASS12-15 is a 12-inch 8 ohm LF driver rated at 100 W RMS. The validated T/S data includes Fs 38 Hz, Qts 0.48, Vas 160.9 L, Xmax 4.7 mm, sensitivity 94 dB, plus 251 cm³ Vd and 68 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 38Hz
- Qts
- 0.48
- Qes
- 0.56
- Qms
- 3.4
- Vas
- 160.9L
- Re
- 5.4Ω
- Le
- 0.70mH
Motor and cone
- BL
- 10.1T·m
- Sd
- 535cm²
- Mms
- 44g
- Xmax
- 4.7mm
- Vd †
- 251cm³
- Voice coil
- 38mm
Power and response
- Sensitivity †
- 94dB
- Manufacturer sensitivity
- 95.5dB
- Power
- 100W
- Impedance
- 8Ω
- Min. impedance
- 5.9Ω
- Range
- 40–4000Hz
- EBP †
- 68 · Sealed or vented
Size and mounting
- Weight
- 2.4kg
Other published values
- Cms
- 0.40mm/N
- Xmech
- 8.7
- Power Program
- 200
Sensitivity shows 94.0 dB, calculated from the T/S values. Lavoce publishes 95.5 dB, 1.5 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 12″
- BL
- 10.1T·m
- Fs
- 38Hz
- Le
- 0.70mH
- Re
- 5.4Ω
- Sd
- 535cm²
- Cms
- 0.40mm/N
- Mms
- 44g
- Qes
- 0.56
- Qms
- 3.4
- Qts
- 0.48
- SPL
- 94dB
- Vas
- 160.9L
- Xmax
- 4.7mm
- Xmech
- 8.7
- Power
- 100W
- Impedance
- 8Ω
- Sensitivity
- 95.5dB
- Low limit
- 40Hz
- Power Program
- 200
- Calculated sensitivity †
- 94dB
- High limit
- 4000Hz
- Manufacturer sensitivity
- 95.5dB
- Min. impedance
- 5.9Ω
- Voice coil
- 38mm
- Weight
- 2.4kg
