Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespVisaton FRS 5 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverFRS series
Visaton
Visaton FRS 5
Visaton FRS 5 is a 2" 8 ohm LF driver rated at 5W RMS. The validated T/S data includes Fs 270Hz, Qts 1.15, Vas 0.2L, Xmax 2mm, sensitivity 84.4dB, plus 2cm³ Vd and 149 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
2"
Impedance
8Ω
RMS Power
5W
Sensitivity
84.4dB
EBP
149
Vented alignment
Vd
2cm³
T/S Parameters
Valid
Fs270Hz
Qts1.15
Qes1.81
Qms3.2
Vas0.2L
Re7.2Ω
Le0.20mH
BL1.6Tm
Sd12cm²
Mms1g
Xmax2.0mm
SPL84dB
Power5W
Impedance8Ω
F Low150Hz
F High20000Hz
Voice Coil14mm
Flux Density0.95T
Pricing & availability
Price definitionsVendor offers
1 vendorsoundimports
Updated 11 Sept 2026· 8Ω
Source: inc VAT
£11.13
inc VAT
Out of stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.1kg
Diameter50.0mm
Cutout Diameter46.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Visaton
FRS 5
2"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
5 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
100%
Similarity
£10.60
Visaton
FRS 5 - 8 OHM
2"
Xmax2mm0%
Qts1.150%
BL1.6Tm0%
Vas0.2L0%
Qes1.810%
74%
Similarity
Dayton Audio
CE53N-4
2"
Xmax2mm0%
Qts1-13%
BL1.7Tm+7%
Vas0.1L-6%
Qes1.3-28%
61%
Similarity
Peerless
HVS-60N18GG01-04
2.5"
Xmax2.2mm+9%
Qts1.3+13%
BL1.8Tm+12%
Vas0.3L+60%
Qes1.84+2%
60%
Similarity
£10.26
Visaton
FRWS 5 - 4 OHM
2"
Xmax2mm0%
Qts1.24+8%
BL1.1Tm-31%
Vas0.2L+25%
Qes2.5+38%
53%
Similarity
Peerless
HVS-60N18PG02-04
2.5"
Xmax1.6mm-21%
Qts1.1-4%
BL1.9Tm+17%
Vas0.2L+49%
Qes1.5-17%
